SMT valves have been engineered to offer customers the ultimate in performance, versatility and value. Our rigorous ex-factory inspections and quality tests enable us to provide customers with quality driven products, which meet or exceed the international industrial standard.
SMT valves are designed with unique features and options which enhance their performance, operational reliability and application versatility. And most valves are available in a choice of body materials including stainless steel, brass, aluminium, engineered plastic, as well as Teflon.
SMT valves are compatible with Asco & SMC & Parker valves.
| Model | 4V110-M5 | 4V110-06 | 4V210-06 | 4V210-08 | 4V310-08 | 4V310-10 | 4V410-15 |
| Working Medium | Clean Air (40 Micrometer Filteration) |
| Ways | 2 Position 5 Port |
| Acting Type | Direct Acting |
| Joint Size | Import=M5
Export=M5
Exhaust=M5 | Import=1/8
Export=1/8
Exhaust=1/8 | Import=1/4
Export=1/4
Exhaust=1/8 | Import=1/4
Export=1/4
Exhaust=1/4 | Import=3/8
Export=3/8
Exhaust=1/4 | Import=1/2
Export=1/2
Exhaust=1/2 |
| Sectional Area | 5.5mm2(CV=0.31) | 12mm2(CV=0.67) | 14mm2(CV=0.78) | 16mm2(CV=0.89) | 25mm2(CV=1.39) | 30mm2(CV=1.67) | 50mm2(CV=2.79) |
| Working Pressure | 0.15~0.9Mpa |
| Guarantee Pressure | 1.2Mpa |
| Working Temperature | -5~60°C |
| Voltage Range | -15%~10% |
| Heat Resistant Grade | B |
| Protective Class | IP65(DIN40050) |
| Coil Type | DIN Type,Flying Leads |
| Max Acting Frequency | 5 Times/s |
Why choose us?
(1) Quality, we only produce top-level quality products, we promise that all of our product's raw material are first class, and good quality system controls, so our goods' quality is very good.
(2) Price, our policy is that "Win-to-Win". That means in view of our long-standing business relationships, we only take small profit to help you for the marketing.
(3) Delivery, we alway have some products in stock, so we can complete the delivery within the time stipulated before.
(4) No MOQ, I think it is an attractive condition to some of you who have no big demands for each items temporarily.
Ningbo Hi-Tech Smart Pneumatic Co., Ltd. is specialized in manufacturing all kinds of hydro pneumatic components, aluminum parts and plastic parts. Our main products are including pneumatic cylinder, (air cylinder), solenoid valve, air filter, air regulator, air lubricator, pneumatic fitting, hydraulic fitting, tubes, muffler (silencer) etc.
SMART PNEUMATIC take the lead in passing ISO9001 quality system certification and UKAS system certification in this industry and equip with a complete set equipment (CNC machine, data control lathe, and all kinds of testing machines) and checkout system. Under the joint effort of all our members, SMART PNEUMATIC has already established a strong foundation today.
SMART PNEUMATICS' Sprit is to give you the best quality, the competitive price, the quick delivery, the perfect service. Our goal to customers is "Always Smart Solution for your Automatic System. "
SMART PNEUMATIC believes our profession and efficiency will make your international business easier and quicker.
SMART PNEUMATIC hopes to work together with you, developing in parallel!
