Three-Way Stainless Steel T/L Port Ball Valve

Three-Way Stainless Steel T/L Port Ball Valve
Price: US $ 99-199/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Paypal

Three-way ball valve
Floating ball
Size:1/2"-8"(15--200mm)   Class:150--300LB (Monolithic&two pieces)
Ends connection:Flange ,butt-welding
Special:Blow-out proof stem
Material:Casting WCB,LCC.LCB,CF3,CF8,CF3M,CF8M,DUPLEX
Seal:PTFE,RPTFE,PPL,PEEK,NYLON
Actuator:Lever

Three-way Ball Valves,L port ball valve,T port ball valve ,flange type
Three way ball valves are suitable for use on various kinds of pipelines of Class150~Class300, PN16~PN40 for switching, dividing, and combining medium flow, of which the operation manners include manual, worm gear, pneumatic or electric actuators, connection manners are in general of flanges. As required by customers, the other type of connection is available too.
Structure and features
L type three way ball valve is used for pipelines to switch the flow direction, being able to switch on two flow lines perpendicular with each other. T type three way ball valve.
May be used to divide, combine or switch the flow direction. T type ball passage is able to switch on three flow lines or switch on two of the three flow lines. T type ball valve may realize two, three or four seats of the functions, however, the specific valve design must draw a distinction between them to realize different function. In this respect, as selecting and ordering by customers, it is necessary to describe in detail the application requirement so as for our principals to make correct design and fitting. Regarding the general Floating three way ball valve, it is unsuited to be used for certain working conditions, which must be made clear to the customers for making right selection. There are many kinds of three way ball valves with unique designs made by our principals to meet customers' special working conditions and requirement. For the common three way ball valves, our principals adopts in general the design of two seats. As required by customers, our principals can also design and manufacture the three way ball valves with four seats.


Type: T port or L port, PTFE seat, reduced bore, with mounting pad ISO5211


No.
PartMaterial
1BallA351-CF8, CF8M, CF3, CF3M, Duplex
2BodyA216-WCB A352-LCB A351-CF8, CF8M, CF3, CF3M, Duplex
3StemASTM A105+ENP A182-F6, F316, F316L, F304L,17-4PH, F51
4Thrust WasherPTFE
5PackingPTFE Graphite
6ScrewASTM A193-B7, B8
7Gland FlangeA216-WCB A351-CF8
8LeverA216-WCB
9Limited Plate1015+Cr. Carbon Steel+Cr.
10RetainerCarbon Steel
11SeatPTFE RTPFE PEEK PPL
12GasketStainless Steel+Graphite S.S.316+Graphite
13BonnetA216-WCB A352-LCB A351-CF8, CF8M, CF3, CF3M, Duplex
14StudASTM A193-B7, B7M, B8, B8M
15NutASTM A194-2H, 2HM, 8, 8M

Prod Model: FYV
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 2''-24''
Class: 150 ~ 300 Lb
O-Ring Sealing: PTFE,NBR,Rptfe
Operation: Gear
Material: Stainless Steel
Connection Form: Flange
Channel: Straight Through Type
Structure: Floating Ball Valve
Type: Floating Ball Valve
Application: Household Usage
Fangyuan Valve Group Co. Ltd, seated at Wuxing Industrial Zone, Oubei, Yongjia County, so called as "Pump & Valve Village of China", close to the national scenic spot Nanxijiang River to the east and facing the downtown of Wenzhou City to the south, and established in 1998 with the former as Zhejiang Fangyuan Valve Manufacturing Co. Ltd, has got a great achievement via hard work and continual going forth ahead and become a magnate of plate gate valve from an unknown small enterprise and leads the future of this industry. Fangyuan Valve Group Co. Ltd was derived from Zhejiang Fangyuan Valve Manufacturing Co. Ltd in 2005 and holds 5 stock subsidiaries, three production bases in Wenzhou, Shanghai and Lishui and a cast base in Lishui, a total registered capital up to 4, 000, 000 USD, a total land area 110000m2, over 600 staff members, 60 of which are technicians, a digital process center and more than 350 sets of various middle and large equipments and an annual output up to 12000 tons.

This Group comes as a key enterprise among the said"Pump & Valve Village of China"and a well known enterprise in the national valve industry and specializes in the production of plate gate valve, gas valve, electric station valve etc., with the development, design and invention patent know-how up to the advanced technical level of the world and the leading level of the nation and some of the products used to replace the imported ones. This Group has been accredited to ISO9001, API6A/6D, CE, AZ etc., won the first prize of scientific advance of Zhejiang Province and elected as a member of the first-grade supply network of China Petroleum, a member of China Petrochemical Resource Market, a member of No. 1 Energy Network, a member for supply of the national electric power system, an appointed production enterprise by Chemical Equipment General Corp., a Wenzhou high-tech enterprise, a start enterprise of Yongjia County, one of the 30 powerful enterprises among the said village and a banking credit AAA grade enterprise in the successive recent years. It holds a powerful strength in the technical, management and market etc. Respects and a notable superiority in the severe market competition.

The products, approved by the nation and province early or late, have been elected as quality products of Zhejiang Province and well-known ones of Wenzhou. This Group follows the guide policy of"takeing people as the base, managing the company with laws, prospecting the enterprise with quality, continuing innovations"and makes the products well sold to all over the country and USA, Canada, the Middle East, Europe etc. World markets, greatly favored by the users therein. Therefore a solid basis has been made for the further open-up of the world market, for the making of Fangyuan brand, for the national industrial progression and for the great target to create a valve magnate of China and step forward to the 50 powerful valve companies of the world.

Slab gate valve: Slab gate and expanding gate, double sealed upstream and downstream design, double block and bleed open and closed design. Size: DN50~DN1400, pressure: PN16~PN420, handwheel, gear, electric, pneumatic.

Fully welded ball valve.

Forged steel valve. Material: A105, LF2, F11, F22, F5, F304, F316, F321 etc.
