Specifications:
1) Design: API 6D
2) Inspection and test: API 6D / API 598
3) Face-to-face: ANSI 16.10 / API 6D
4) Flange: ANSIB16.5 / ANSIB16.47
5) Size: 2" - 48"
6) Class: 300LB-2500LB
7) Temperature: -29 ~ 121C
8) Body / Bonnet: WCB / WCC / 304 / 316
9) Seat: A105 +ENP + PTFE / 13% Cr + PTFE / 304+PTFE / 316 +PTFE
10) Disc: 13% Cr / A105 + ENP / 304 / 316
11) Stem: 13% Cr / 304 / 316
Inner Packing:
Plastic Package
Outer Packing:
Wooden Package
Wenzhou Better Valve Co., Ltd. Was established in 2007, integrating the design, production, examination with sales into a body in the field of valve industry.
BETTER VALVE is also equipped with the test lab with examination equipment for material chemical composition analysis, physical property and non-destructive examinations such as RT, UT, MT, and PT.
