| Price: | US $ 3000/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 20/Piece |
| Pay Type: | T/T |
| Standard or Nonstandard: | Standard | Structure: | Diaphragm | Pressure: | High Pressure |
| Power: | Hydraulic | Material: | Forged | Temperature of Media: | Medium Temperature |
| Media: | Oil | Port Size: | 4 1/16 | Place of Origin: | Shandong, China (Mainland) |
| Model Number: | RT-MF008 | Brand Name: | RT |
PFFA Series Slab Gate Valve
·Full-bore design eliminates pressure drop and eddy effectively,and slows up erosion to valve from solid particle in fluid.
·It is metal sealed between bonnet and valve body,valve plate and valve seat,valve seat and valve body;
·Spray welded hard alloy on the surfaces of valve plate and valve seat with the characteristics of good wear resistance and corrosion resistance;
·Bonnet and valve steam are designed with back sealed construction,which is convention for renewing sealing ring of the valve rod under pressure;
·Seal grease injection valve is installed to one side of the bonnet;
·Working pressure:2,000PSI~20,000PSI
·Nominal diameter:2 1/16″~4 1/16″(52mm~103mm)
·Working medium: petroleum, natural gas, mud, gas containing H2S and CO2
·Working temperature:-60ºC~121ºC(KU level)
·Material grade:AA,BB,CC,DD,EE,FF,(HH)
·Specification grade:PSL1~4
·Performance requirement:PR1~2
PFF Series Slab Valve
·Full-bore design eliminates pressure drop and eddy effectively,and slows up erosion to valve from solid particle in fluid.
·It is metal sealed between bonnet and valve body,valve plate and valve seat,valve seat and valve body;
·Spray welded hard alloy on the surfaces of valve plate and valve seat with the characteristics of good wear resistance and corrosion resistance;
·Bonnet and valve steam are designed with back sealed construction,which is convention for renewing sealing ring of the valve rod under pressure;
·Seal grease injection valve is installed to one side of the bonnet in order to supply grease and improve sealing performance and lubricity of valve plate and valve seat;
· Equipped with balance guide rod,which plays a part in keeping the valve upright to reduce operating torque;
·Working pressure:2,000PSI~20,000PSI
·Nominal diameter:2 1/16″~4 1/16″(52mm~103mm)
·Working medium: petroleum, natural gas, mud, gas containing H2S and CO2
·Working temperature:-60ºC~121ºC(KU level)
·Material grade:AA,BB,CC,DD,EE,FF,(HH)
·Specification grade:PSL1~4
·Performance requirement:PR1~2
Check Valve
This product is designed and manufactured with the requirement of API Spec 6A(Edition 20), meanwhile can be compatible and used interchangeably with domestic and overseas products meeting API Spec 6A standard.
·Working medium flows in one direcion
·Working pressure:2,000PSI~20,000PSI
·Nominal diameter:2 1/16″~4 1/16″(52mm~103mm)
·Working medium: petroleum, natural gas, mud, gas containing H2S and CO2
·Working temperature:-60ºC~121ºC(KU level)
·Material grade:AA,BB,CC,DD,EE,FF,(HH)
·Specification grade:PSL1~4
·Performance requirement:PR1~2
| Prod Model: | from 2000 PSI to 2000 PSI |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material Grade: | AA\Bb\Cc\Dd\Ee\FF\(Hh) |
| Structure: | Angle Type Globe Valve |
| Standard: | API |
| Sealing Form: | Gland Packings Globe Valve |
| Application: | Bellows Globe Valve |
| Stem Thread Position: | Outside and Inside |
