Wafer Butterfly Valve with Signal Flange

Wafer Butterfly Valve with Signal Flange
Price: US $ 20/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Here is the features:
1. Structure simple is compact, stable positioning, and the weight is light.
2. Designs reasonably, the assembling and dismantling and installation is easy, to be advantageous.
3. Minimized operating torque. Lever, gear, pneumatic and electric actuators can be chosen.
3. Rubber backed seat with stable valve torque. No leakage under the rated pressure.
4. Special design, high flow rate and low flow resistance.

Application:
1. These products are mainly used for pipeline flow, pressure and temperature control of various industrial automation productiong, for example: Electricity, petrifaction, metallurgy, environmental protection, energy management, fir-fighting systems.
2. Simultaneously they have good fluid control properties, and can operate simply.
3. They are not only widely used in general industries as petroleum, coal gas, chemical engineering, water treatment, but also used in the cooling water system of thermal power plant.

Packaging Detail: Inner packing: Individual polybag for each valve Outer packing: Plywood box~veneer case, standard size is 1150*950*550mm/1150*950*600mm We can also make the case according to consumer's requirement or the real size of valves.


Series
Wafer  butterfly valve
SizeDN40-DN1200/1.5" -48"
End flangeANSI B 16.1, ASTM B 16.47, EN 1092, AS 2129
Face to faceANSI B 16.10
Top flangeISO 5211
Nominal pressureDN40-DN600(1.5" -24" ) PN1.0/1.6MPa(150/200PSI) DN700-DN1200(28" -48" ) PN1.0MPa(150PSI)
BodyCast Iron/Ductile Iron/WCB/Carbon steel/AL-Bronze/CF8, SS304/CF8M, SS316
Disc.Ductile Iron/Ni-plated ductile iron/Nylon-plated ductile iron/AL-Bronze/Rubber lined Disc/1.2501/1.4529/CF8/CF8M/Hastelloy Alloy/Monel
StemSS416/SS304/SS316/SS431/17-4PH/Monel
SeatNBR/Hypalon/EPDM/Neoprene/NR/Wear-Resistant EPDM/Viton/Silicon/Heat-Resistant EPDM/White EPDM/EPDM/PTFE
Suitable temperatureNormal Temperature -45 ~150
MediumFresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc.
Prod Model: D71X-10/16
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Colour: Blue, Red
Power: Lever
Seals: Rubber
Material: Casting
Connection Type: Wafer
Certificate: ISO, CE
Port Size: Dn40-1400
Connection Form: Wafer
Work Pressure: Low Pressure (',Pn<1.6mpa)
Structure: Centre Sealing
Seal Form: Force Sealed
Working Temperature: Normal Temperature (',-40??C
Application: Household Usage
Material Of Seal Surface: Soft Sealed
TIANJIN WORLDS VALVE Ltd. is located at TIAN JIN BIN HAI, , it is only 3 kilometers away from Tianjin Xingang Port, TIANJIN WORLDS VALVE Ltd. focuses on producing, installing, sale and service. The main products ranges from Center Line Butterfly Valve, Flanged Butterfly Valve, Metal Butterfly Valve, Dual Plate Check Valve, Gate Valve, Waterpower Control Valve, Microresistance Slow Close Check Valve, Multi-function Pump Control Valve to their series products. Moreover, we can produce control valve and pressure reducing valve with different materials, pressures, specifications, actuation ways. Our products have more than 50 serials and 1200 species, the annual production output is more than 8.000 metric tons. WORLDS valves sells well all over China and have been exported to Europe, America and other countries and areas, they are widely used in water supply and drainage, electric power, petrol chemical industry, metallurgy and other trades. The products are creative with good quality, cheap price and excellent credit, so far we got a good feedback from our customers.

WORLDS has excellent technicians and engineers, at the same time it has a lot of large and middle machines including 178 sets of manufacturing equipments and 32 sets of performance testing equipments imported from overseas. Our products have original design, exquisite technique, perfect manufacture and complete testing ways. It has passed ISO 9001 international quality system certification of DNV. WORLDS will supply best products and service for all customers.
