Wafer Type Butterfly Valve, Made in China, American Standard Butterfly Valve (D371 butterfly Valve)

Wafer Type Butterfly Valve, Made in China, American Standard Butterfly Valve (D371 butterfly Valve)
Price: US $ 320/Piece
Trade Terms: FOB,CIF,DAP
Min Order: 5/Piece
Pay Type: L/C,T/T,Western Union
Wafer type butterfly valve, American standard butterfly valve made in China 1) Design of JINGJIA butterfly valve Centerline structure, pinless one shaft design. Disc has two-way bearing, no installation direction requirements. Non-backed replaceable seat with good performance and a longer working life. Square and short neck for lable use and cost saving. Easy installation, no need flange gasket. 2)Applications of JINGJIA Butterfly Valve These butterfly valves are widely used in water source projects, urban water supply And drainage, sewage treatment, electric power, petroleum, petrochemical, Heat supply, shipbuilding, medicine and metallurgy industries. Valves used for regulating or cutting off liquids in pipelines.Liquids available include water, sewage, sea water, air, foodstuff and oil. To NACE MR 01 75 is also availabe. API 609 Thanks for  viewing our butterfly Valve We sincerly know the importance of quality and dilivery time . Should you have any questions or require further assistance , please feel free to contact us Any of your inquiry will be highly appreciate and reply in 24 hours . Best regards .
Size DN50mm-DN600mm
Design standard API609/EN593
Pressure rating DIN PN10/PN16, BS4504PN10/PN16/PN25/PN40, ANSI class125#/class150#/300#/600#
Face to face API609/EN558-1
Body Ductile iron/Cast iron/cast steel /stainless steel /bronze
Disc Ductile iron/Cast iron/cast steel /stainless steel /bronze
Stem SS410
Seat EPDM/NBR/Viton/PTFE

Prod Model: D371 butterfly Valve
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimensions: Dn50 to Dn2400
Design Standard: API 6D, Asme B16.34, API 608, Bs 5351, Mss Sp-72
Working Pressure: 0.6mpa to 1.6mpa
Work Pressure: Low Pressure (',Pn<1.6mpa)
Material Of Seal Surface: Soft Sealed
Connection Form: Lug Support
Structure: Centre Sealing
Seal Form: Force Sealed
Working Temperature: Medium Temperature (',120??C
Application: Oil and Gas Industrial
JINGJIA VALVE GROUP, founded in 1984, is a national level non-regional group that integrates the professional R&D, manufacturing, sales and services of pressure vessels. The headquarter is located at No. 4383, Cao An road, Shanghai with 106.8 Million registered capital and controls six subsidiaries. It is equipped with modernized technical research and development center, computer controlled test center, spray coating assembly line system, and self-developed automated butterfly valve and ball valve lifespan testing center. The group occupies 40, 000 square meters of total area and over 30, 000 square meters of construction area with 435 employees. The turnover of JINGJIA VALVE GROUP in year 2010 is over 150 Million RMB, of which export products account for 4.6%. The ZHEJIANG JINGJIA VALVE CO. Ltd is located in Oubei Town, Yongjia County.

The Group has obtained ISO 9001: 2008 quality system certificates from United Kingdom Accreditation Service (UKAS) and China Classification Society (CCS), API 6D and API 609 certificates from American Petroleum Institute, European Safety Mark (CE/PED), National License for Manufacturing Special Equipment (TS), Type Approval certificate from Bureau Veritas (BV), American Bureau of Shipping (ABS), and China Classification Society (CCS). Meanwhile, the testing certificates of LR, GL, DNV etc, can be also provided according to client's requirement. The group is the governing unit of China Valve Association, a 1st-Class supplier of SINOPEC, CNPC and State Grid, the compiler member of National Valve Standard, a deputy director member of China Shipbuilding Industry Corporation (CSIC) standardize research center. The group has obtained multiple national patents and new product development projects license at the provincial level. The grooved-ends valve which is developed by the group has filled the blank in domestic market. The group is also the executive editor of three industry standards, compiler member of seven industry standards, the executive editor of National Standard of automated butterfly valve and ball valve for marine services, an AAA credit and honoring-all-contracts enterprise.

The group mainly manufactures butterfly valve, ball valve, gate valve, globe valve, marine valve, waterworks valve, hydraulic systems and its accessories with material cast steel, stainless steel, cast iron, bronze, etc. And actuation including manual, electric, pneumatic, hydraulic etc. The pressure range is from 0.1Mpa to 42Mpa and the size range is from DN 6 to DN 3200mm. All the products are manufactured and inspected in strict accordance with API, DIN, JIS, GB and other industry standards, and excellent in substituting imported items and also being exported.

Under the flag of "JINGJIA" brand, with the JINGJIA spirit in mind, "Technology innovation, Stable Quality, Customer Oriented, Sincerity for Trust, No best but only better", The JINGJIA VALVE GROUP is always ready to provide clients with more satisfactory products and services.
