Water Control Spline Butterfly Valve

Water Control Spline Butterfly Valve
Price: US $ 8/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 10/Piece
Pay Type: L/C,T/T
Water control spline butterfly valve

Wafer Type Butterfly Valve with Aluminum handle, butter fly valves, cast iron valve, wafer valve, wafer butterfly valve, butterfly valve manufacturer, stainless steel valves, butterfly valve with actuator, butterfly control valve, what is a butterfly valve

Related Keywords: Wafer butterfly valves, centerline butterfly valves, wafer valves, butterfly valves

Delivery & Packaging
Delivery Detail: General within 30 days or according to the order quantity.
Packaging Detail: Plywood case. (each PC into one bubble plastic bag, several PCS into one Plywood case).

Specifications
1. Working temperature: -45 to 200 Celsius.
2. Top Flange: ISO5211 or factory standard.
3. Nominal diameter: DN25~DN1200 (1"~48").
4. Design standard: API 609, BS EN 593, MSS SP-67, BS5155.
5. Suitable media: Petroleum, chemical industry, water, oil, gas etc.
6. Pressure test: API 598, ISO 5208, EN12266-1, DIN3230, BS5155.
7. Working pressure: PN10/PN16/PN25 or 10Bar/16Bar/25Bar or class 125/150.
8. Operator: Handle lever, worm gearbox(reducer), electric or pneumatic actuators etc.
9. Face-to-face conform to API 609, ISO 5752, BS EN 558, BS 5155, MS SP-67, DIN3202.
10. Flange: ANSI B 16.1 125/150, AS2129, BS4504, BS EN 1092, BS 10 table D/E, DIN 2501 PN 10/16/25, JIS 5K/10K.

Main parts materials
A) Key: Carbon Steel.
B) O-Ring: NBR, EPDM, Neoprene, Viton.
C) Bushing: PTFE, Nylon, Lubricated Bronze.
D) Seat: NBR, EPDM, Neoprene, Viton, PTFE, BUNA, Hypalon.
E) Taper Pin: Carbon steel; Stainless Steel: ASTM A276 Type 410/420/304/316, EN 1.4501.
F) Stem: Zinc Plated Carbon Steel; Stainless Steel: ASTM A276 Type 316/304/410/420, ASTM A582 Type 416.
G) Body/Disc: Cast Iron(CI): ASTM A126CL. B, DIN1691 GG25, EN 1561 EN-GJL-200, GB12226 HT200;
Ductile Iron(DI): ASTM A536 65-45-12, DIN 1693 GGG40, EN1563 EN-GJS-400-15, GB12227 QT450-10;
Stainless Steel: ASTM A351 CF8, CF8M; CF3, CF3M;
Carbon Steel: ASTM A216 WCB.
Prod Model: D71X
Markets: South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Work Pressure: Low Pressure (',Pn<1.6mpa)
Material Of Seal Surface: Soft Sealed
Connection Form: Lug Support
Structure: Centre Sealing
Seal Form: Force Sealed
Working Temperature: Normal Temperature (',-40??C
Application: Household Usage
Tianjin Future Valve Co., Ltd. is specialized in research, development, production and sale of butterfly valve, check valve, gate valve for years. With professional staff, scientific management system, strong production capacity, strict quality control, on-time delivery, quick response service and individual approach to every customer, we have confidence that we could establish long-term, win-win partnership with you!
