Technical data :
Design:API 609\BS5155\EN593\GB/T12238\DIN3354
Face to Face:API609\ DIN3202 K1\BS5155\EN558\ISO5752\ASME B16.10
Flange End:ASME B16.1 CLASS 125\ASME B16.5 CLASS 150\ASME B16.47\BS EN 1092 PN6/PN10/PN16\JIS B 2220 5K/10K/16K\BS 10 Table D/Table E
Top Flange:ISO5211(According to customer's needs)
Inspection:API598\EN12266-1\ISO5208
Size Range:DN50-DN1600/2"-64" Temperature:-40°C to +200°C (Depending on pressure, medium and material)
Medium:freshwater\ sewage\seawater\air\vapor\food\oils\medicine\ alcohol\salt
Main Material List
BODY:CI, DI, WCB, WCC, LCB, LCC, CF8, CF8M, CF3, CF3M, C95400, C95800, SAF2205, SAF2507, F51, 1.4529... SEAT:BUNA-N, NBR, EPDM, HYPALON, NEOPRENE, VITON, FKM, PTFE, RPTFE, TEFLON, NATURAL RUBBER... DISC:CF8, 304, CF3, 304L CF8M, 316, CF3M, 316L, SAF2205, SAF2507, F51, 1.4529, C95400, C95500, C95800, MONEL.. STEM:F410, F420, F430, F431, F304, F316, MONEL 400, MONEL K500
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
