Specifications
Size : DN50~DN400
Rating : 150~1500LB(PN16~PN250)
Features:
1. Connection Form: Flanged type, Welded type, Threaded type.
2. Design Standard: API 6D, BS 5351, ASME B16.34, ANSI B16.1, API 608, MSS SP-72, EN13942, DIN 3202, DIN3357, DIN 3352, GB/T 19672, GB/T 12237.
3. Face to Face Dimension: ANSI B16.1, DIN3202, API 6D, EN 558, EN 12982, GB/T 12221.
4. Flange Drilling: BS4504, DIN2533, ASME B16.5, ASME B16.25, ASME B16.47, EN 1092-1,EN 12627, MSS SP-44, GB/T 9113.
5. Test: API598, API 6D, BS 6755, GB/T 13927, JB/T9092.
6. Coating: Epoxy Powder Coating, Mirror Polished Surface, or as customers' requirement.
7. Certificate: ISO 9001, ISO14001, ISO18001, API 6D, API 607, API 6 FA, CE, GOST, TS.
Material of Ball Valve:
1. Body: Grey Cast Iron: GG25, GGG40, Cast Iron: FC200, FCD400, Alloy Steel,Dual-Phase Steel, Carbon Steel: WC6, WC9,Stainless Steel: SS304, SS316, SS 304 L, SS 316 L
2. Bonnet: Grey Cast Iron: GG25, GGG40, Cast Iron: FC200, FCD400, Alloy Steel, Dual-Phase Steel, Carbon Steel: WC6, WC9,Stainless Steel: SS304, SS316, SS 304 L, SS 316 L
3. Ball: SS 304, SS 316, SS 304 L, SS 316 L
4. Seat: PTFE, RPTFE, EPDM, SILICONE, NBR
5. Gasket: PTFE, RPTFE, EPDM, SILICONE, NBR
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
