Wras Non Rising Stem Resilient Seated Gate Valve

Wras Non Rising Stem Resilient Seated Gate Valve
Price: US $ 100/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,Money Gram,Western Union
Resilient seat gate valve is a high quality green product, R & D by our company and Shanghai University importing Germany advanced technologies. Widely used in water supply, sewage disposal, electric power, chemical, shipping, construction etc.
Features
Light Weight;
No - grooved body cavity;
Wedged rubber - packed wholly Close tolerance cast valve body;
Three O-ring
Beneficial to drinking


APPLICABLE STANDARDS
American Standard
Design to ANSI/AWWA C509
Face to face dimension to ASME B16.10-2000(ISO 3 series)
Flange and drilling To SME/ANSI B16.42-1998
British Standard
Design to BS5163, BS5150
Face to face dimension to BS5163(ISO 3series, ISO19 series)
Flange and drilling To BS4504 part1(EN1092)
Germany Standard
Design to DIN3352
Face to face dimension to DIN3202(F4: ISO 14 series; F5: ISO 15 series)
Flange and drilling to BS EN1092

TECHNIC CRITERION
Nominal pressure: 1.0~1.6MPa
Nominal diameter: DN40-1200mm
Applicable medium: Water, sewage, oil, gas etc.
Applicable temperature: ≤ 120 degree centigrade
Main material of valve: Ductile iron, iron


Prod Model: Z45X
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe
Pn:1.0,1.6mpa Or 125lb ,150lb: Dn:40-1200mm
Material: Carbon Steel
Connection Form: Flange
Seal Surface: Wedge Gate Valve
Thread Position Of Valve Rod: Inside Gate Valve
Application: Household Usage
Shanghai Kangquan Valve Co., Ltd. is a professional valves manufacture, with a high-quality workforce of 218, 10 Senior Engineers, 25 MID-level technicians. Provided with two production bases, it covers an area of 15000 square meters with strong technical forces, well-equipped 90 kinds of machine tools and 2, 500 tons of valves output capacity annually.

Kangquan have accumulated a wealth of information and experience in this field and enjoy a high reputation in dealing with both domestic and overseas trading. In 1998, "green valve P&R&D Unit " cooperated with Shanghai University' S has been set up to development of green products successfully-soft seal epoxy coating gate valve, and has gained P&R&D engineering item Third Honors. Our products line includes various kinds of gate valves, globe valves, ball valves, check valves, cock valves, butterfly valves, etc. Always under the ISO 9001 quality assurance system, up to the international advanced standards of ANSI, API, JIS, DIN, BS and so on. Materials mainly include carbon steel, stainless steel, ductile iron and so on. With hand wheel, worm-gear actuator, pneumatic and electric actuator to be selected, widely used in the industries of petrochemical, natural gas, metallurgy, electric power, pharmaceutical, construction, etc...

With highly qualified professionals and first class service, Shanghai Kangquan Valve Co., Ltd. Has established a highly respected enterprise which has been relied on for years. And we will continuously offer customers the most accurate and high quality delivery service possible.

Excellent quality assurance is our sales purpose,

Competitive price is our sales policy,

On time product delivery and responsive service is our standard.

Shanghai Kangquan Valve Co., Ltd. Hopes to work together with you for a better future. Let' S work together building a mutually beneficial relationship that will last for years.
