Bolted bonnet, reducing bore and full bore, outside screw and yoke (OS&Y). End connection as threaded or socket welded or butt-welded, designed to API 602.
Apply to such industries as petroleum, chemical industry, papermaking, shipping, electricity, machinery, etc.
(NPS) Specification | F.P | | 3/8 | 1/2 | 3/4 | 1 | 1 1/4 | 1 1/2 | 2 |
Structural Length | L | CL2500 | 186 | 186 | 186 | 186 | 232 | 232 | 310 |
CL4500 | 200 | 200 | 200 | 200 | 250 | 250 | 330 |
Handwheel diameter | W | CL2500 | 200 | 200 | 200 | 200 | 280 | 280 | 300 |
CL4500 | 280 | 280 | 280 | 280 | 300 | 300 | 320 |
Center Height(open) | H | CL2500 | 333 | 333 | 333 | 333 | 406 | 406 | 524 |
CL4500 | 400 | 400 | 400 | 400 | 460 | 460 | 540 |
Bore Diameter of Flow Channel | d | CL2500 | 9 | 11 | 14 | 19 | 25 | 28 | 35 |
CL4500 | 9 | 11 | 11 | 15 | 20 | 26 | 28 |
Weight | | CL2500 | 12.3 | 12.3 | 11.6 | 10.8 | 28 | 26.4 | 43.8 |
CL4500 | 30 | 30 | 30 | 30 | 30 | 36 | 58 |
Located in Oubei, which is known as "Village of Chinese Pumps & Valves", Yongjia Kaizheng Valve Co., Ltd. specializes in producing various kinds of forged steel valves.
Our products are gate valves, globe valves, check valves, ball valves and bellow valves.
DN: DN10- 1050mm (3/8"-42")
Nominal pressure: PN1.6~42Mpa (150Lb~2500Lb)
Material: A105, Lf2, F5, F11, F22, 304, 304L, 316, 316L
Standard: API, ANSI, DIN, JIS, GB, BS
Our company insists on "Good Quality, Customer Highest".
