Technical Parameter:
Pressure class:1.0Mpa,1.6Mpa
Pressure resistant of valve body:1.5Mpa,2.4Mpa
Test of sealing:1.1Mpa,1.76Mpa
Working temperture:0-80°C
Applicable mediums:water,gas,etc
Material Of Parts:
No. | Item | Material |
1 | Valve Body | Cast Steel,Ductile Iron |
2 | Valve Gate | EPDM Coated Outside Ductile Iron |
3 | Bolt | Galvanized |
4 | Sealing Ring | NBR |
5 | Valve Cover | Cast Steel,Ductile Iron |
6 | Valve Stem | Stainless Steel |
7 | O-shape Sealing Ring | NBR |
8 | Thrust Pad | Bronze |
9 | Shaft Sleeve | Bronze |
10 | Bolt | Galvanized |
11 | Shaft Cover | Cast Iron,Ductile Iron |
12 | Dust Cover | NBR |
13 | Hand wheel | Cast Steel |
14 | Fastening Nut | Galvanized |
