| Prod Model: |
Z41X |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
40mm-400mm |
| Material: |
Cast Iron |
| Connection Form: |
Flange |
| Seal Surface: |
Wedge Gate Valve |
| Thread Position Of Valve Rod: |
Outside Gate Valve |
| Application: |
Household Usage |
Product Description
DIN Resilient Seat OS&Y Gate Valve F4
DIN Resilient seat OS &Y gate valves is used to turn on or off the pipelines ,suitable medium are water,oil,vapor,etc.It can be used in chemical industry,pharmaceutical industry etc.
Specifications
1)Nominal pressure:1.0MPa/1.6MPa
2)Body:Ductile iron
3)Bonnet:Ductile iron
4)Disc:Ductile iron
5)Stem:Stainless steel
6)Shell test:1.5MPa/1.4MPa
7)Seal test:1.1MPa/1.76MPa
8)Actuator:Manual
Standard
Design standard:DIN3352F4
Face to face:DIN3202
Flange standard:DIN2501
| DN | 50-800 | mm |
| PN | 1.0 | 1.6 | 2.5 | MPa |
| Casing test | 1.5 | 2.4 | 3.75 |
| Sealing test | 1.1 | 1.76 | 2.75 |
| Hermetic seal test | 0.6 | 0.6 | 0.6 |
| Suitable temperature | ≤100 | ºC |
| Suitable | Water,sewage
|
