Forged Steel Bellow Sealed Globe Valve
| Price: |
US $ 11.5/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
JW41H |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Design: |
BS1868, API 602 |
| Face To Face: |
Asme B16.10 |
| Flange: |
ANSI B16.5 |
| Test & Inspect: |
API 598 |
| Structure: |
Through Way Globe Valve |
| Sealing Form: |
Bellows Globe Valve |
| Stem Thread Position: |
Outside Screw Stem Globe Valve |
| Application: |
Bellows Globe Valve |
| Standard: |
ANSI |
Product Description
Bellow Sealed Globe Valve 800Lb
Standard Material Specifications
NO. Part Name CS to ASTM AS to ASTM SS to ASTM
Type A105 Type A182 F22 Type A182 F304 Type A182 F316(L)
1. Body A105 A182 F22 A182 F304(L) A182 F316(L)
2. Disc A276 420 A276 304 A276 304(L) A276 316(L)
3. Gasket Corrugated SS + graphite SS + PTFE
4. Bonnet Bolt A193 B7 A193 B16 A193 B8 A193 B8M
5. Stem A182 F6 A182 F304 A182 F304(L) A182 F316(L)
6. Bellow Pipe SS
7. Bonnet A105 A182 F22 A182 F604(L) A182 F316(L)
8. Stem Packing Flexible Graphite PTFE
9. Pin A276 420 A182 F304
10. Gland A276 420 A182 F304
11. Gland Eyebolt A193 B7 A193 B16 A193 B8 A193 B8M
12. Gland Flange A216 WCB A351 CF8
13. Gland Nut A194 2H A194 4 A194 8 A194 8M
14. Bearing Washer SS
15. Yoke Nut A276 410
16. Nameplate SS
17. Handwheel A197
18. H. W. Nut A194 2H A194 4 A194 8 A194 8M
Suitable Medium W. O. G. etc W. O. G. etc HNO3, CH3OOH etc
Suitable Temperature -29 TO 425 -29 TO 550 -29 TO 180
| NPS | Conv. | 3/8 | 1/2 | 3/4 | 1 | 1-1/4 | 1-1/2 | 2 |
| Full |
| 3/8 | 1/2 | 3/4 | 1 | 1-1/4 | 1-1/2 |
| L | 79 | 79 | 92 | 111 | 120 | 152 | 172 |
| H(OPEN) | 220 | 220 | 225 | 244 | 321 | 321 | 347 |
| W | 100 | 100 | 100 | 125 | 160 | 160 | 180 |
| Weights | Bolted | 3.2 | 3.0 | 4.8 | 7.9 | 11.0 | 16.8 | 25.2 |
| Welded | 3.0 | 2.8 | 4.8 | 7.0 | 9.6 | 13.5 | 20.2 |
