Globe Valve (GBV-032-G)
| Price: |
US $ 36/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
GBV-032-G |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Design: |
ANSI/DIN//Bs |
| Size: |
Dn15-Dn300 |
| Pressure: |
Pn10/Pn16/150lb/125lb |
Product Description
Globe Valve
More information is available upon receipt of your inquiry! Please feel free to contact for details!
|
Technique standard |
|
Design |
GB/T 12235 |
|
Face to Face |
GB/T 12221 HG/T 3704-2003 ASME B16.10 |
|
Flange dimension |
HG20592-97 ANSI B16.5a |
|
Mode of driving |
Hand, electrically-driven, air-operated |
|
Nominal Pressure |
0.6-2.5MPa/Class 150 |
|
Pressure test |
GB/T 13927, API 1598 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Main parts material specifications |
|
Name |
Refined D. I |
Cast steel |
Stainless steel |
|
QT |
C |
P |
R |
RL |
RL |
|
Body/Bonnet |
QT400 |
WCB |
CF8 |
CF8M |
CF3 |
CF3M |
|
Stem |
2Cr13 |
2Cr13 |
CF8 |
CF8M |
CF3 |
CF3M |
|
Inner lining |
FEP(F46)/PTFE(F4)/PFA/PO/PE |
|
Daiphragm |
FEP(F46)/CR/PFA/FPDM |
|
Disc |
QT400 |
WCB |
CF8 |
CF8M |
CF3 |
CF3M |
|
Bolt |
35 |
35 |
SS316 |
SS316 |
SS302 |
SS302 |
|
Nut |
45 |
45 |
SS304 |
SS304 |
S304 |
SS304 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Main dimensions |
|
DN |
L |
D |
D1 |
D2 |
f |
b |
Z-Φ d |
D0 |
H |
|
15 |
125 |
95 |
65 |
45 |
3 |
15 |
4-14 |
120 |
120 |
|
20 |
135 |
105 |
75 |
55 |
3 |
17 |
4-14 |
120 |
120 |
|
25 |
145 |
115 |
85 |
65 |
3 |
17 |
4-14 |
160 |
130 |
|
32 |
160 |
140 |
100 |
75 |
3 |
19 |
4-18 |
160 |
135 |
|
40 |
180 |
150 |
110 |
85 |
3 |
19 |
4-18 |
180 |
160 |
|
50 |
210 |
165 |
125 |
100 |
3 |
21 |
4-18 |
200 |
165 |
|
65 |
250 |
185 |
145 |
120 |
3 |
21 |
4-18 |
250 |
200 |
|
80 |
300 |
200 |
160 |
135 |
3 |
22 |
8-18 |
280 |
220 |
|
100 |
350 |
220 |
180 |
155 |
3 |
23 |
8-18 |
300 |
275 |
|
125 |
400 |
250 |
210 |
185 |
4 |
24 |
8-18 |
320 |
335 |
|
150 |
460 |
285 |
240 |
210 |
4 |
26 |
8-23 |
350 |
380 |
|
200 |
570 |
340 |
295 |
265 |
4 |
26 |
12-23 |
450 |
500 |
|
250 |
680 |
405 |
355 |
320 |
4 |
28 |
12-26 |
500 |
575 |
Everbearing Engineering Co., Ltd. is a manufacturer of various valves with well-equipped testing equipment and strong technical force.
Since 1994, We have passed API-Q1, and gotten the ISO 9001: 2000 certification. And after years of experience in supplying valves abroad, Everbearing has been recognized as a skilled and credible supplier with most-trusted, highest-quality products.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in water, oil, gas and other industries.
Sincerely, we hope to make Everbearing brand as a famous brand with domestic and international customers. And we do our best to improve Everbearing as a high-class valve manufacturer.
We are looking forward to establishing relationships with you in the near future.
Everbearing Engineering Co., Ltd. is a manufacturer of various valves with well-equipped testing equipment and strong technical force.
Since 1994, We have passed API-Q1, and gotten the ISO 9001: 2000 certification. And after years of experience in supplying valves abroad, Everbearing has been recognized as a skilled and credible supplier with most-trusted, highest-quality products.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in water, oil, gas and other industries.
Sincerely, we hope to make Everbearing brand as a famous brand with domestic and international customers. And we do our best to improve Everbearing as a high-class valve manufacturer.
We are looking forward to establishing relationships with you in the near future.
