Lubricated Metal Seated Plug Valve
Price: |
US $ 40-860/Piece |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T |
Prod Model: |
X47H |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Desing And Manutacture: |
API 6D API 599 Asme B16.34 |
Face To Face/End To End: |
API 6D Asme B16.10 |
Flange Dimensions: |
ANSI B16.5 Asme B16.25 |
Pressure Temperature Lating: |
ANSI B16.34 |
Inspection And Test: |
API 598 API 6D |
Product Description
INVERTED PRESSURE BALANCE LUBRICATED PLUG VALVE
Main Structural Features
Bolt cover,structure of flip-chip balanceable pressure and light on/off operation.An oil grove is set between valve body and seal surface,which may infuse the seal grease to increase the seal capability.
Standards Compliance
Design and Manufacture: API 599, API 6D
Face to face(end to end): ANSI B 16.10
Flanged connection: ANSI B16.5
Butt welded end: ANSI B16.25
Test and inspection: API 598, API 6D
Main Pants Materials
NO. | Part name | Material |
A216 WCB | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
1,2 | Body/Nut | A193 B7/A194 2H | A193 B8/A194 8 | A193 B8M | A194 8M |
3 | Cover | A216 WCB | A351 CF8 | A351 CF8M |
4 | Gasket | Flexible graphite+stainless steel/PTFE |
5 | Plug | A182 F304 | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M |
6 | Body | A216 WCB | A351 CF8 | A341 CF8M | A182 F304L | A351 CF3M |
7 | stem | A182 F410 | A182 F304 | A182 F316 | A182 F304L | A351 CF3M |
8 | O ring | NBR/FEP/SBR |
9 | Packing | Flexible graphite/PTFE |
10 | Gland | A216 WCB | A351 CF8 | A351 CF8M |
11,12 | Oichozzle/check valve | Material see body |
13 | Wrench | ASTM A47-32510 A216 WCB |
Dimension & Weight (mm&Kg)
Dimensions |
Class 150Lb |
Size | inch | 1/2 | 3/4 | 1 | 1-1/4 | 1-1/2 | 2 | 2-1/2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 |
L-RF | mm | 108 | 117 | 127 | 140 | 165 | 178 | 190 | 203 | 229 | 254 | 267 | 292 | 330 | 356 | 381 |
H | mm | 180 | 180 | 185 | 200 | 210 | 215 | 250 | 270 | 300 | 340 | 365 | 400 | 450 | 510 | 590 |
W | mm | 400 | 400 | 500 | 500 | 600 | 600 | 820 | 820 | 300 | 300 | 320 | 320 | 350 | 380 | 380 |
Weight | Kg | 10 | 12 | 14 | 17 | 19 | 21 | 29 | 33 | 48 | 75 | 98 | 125 | 171 | 230 | 370 |
Dimensions |
Class 300Lb |
Size | inch | 1/2 | 3/4 | 1 | 1-1/4 | 1-1/2 | 2 | 2-1/2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 |
L-RF,BW | mm | 140 | 152 | 165 | 178 | 190 | 216 | 241 | 283 | 305 | 381 | 403 | 419 | 457 | 502 | 762 |
H | mm | 180 | 180 | 185 | 200 | 210 | 215 | 250 | 270 | 300 | 340 | 365 | 400 | 450 | 510 | 590 |
W | mm | 400 | 400 | 500 | 500 | 600 | 600 | 820 | 820 | 300 | 300 | 320 | 320 | 350 | 380 | 380 |
Weight | Kg | 12 | 14 | 16 | 19 | 21 | 24 | 31 | 36 | 61 | 86 | 130 | 190 | 225 | 380 | 560 |
Dimensions |
Class 600Lb |
Size | inch | 1/2 | 3/4 | 1 | 1-1/4 | 1-1/2 | 2 | 2-1/2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 |
L-RF,BW | mm | 165 | 190 | 216 | 229 | 241 | 292 | 330 | 356 | 432 | 508 | 559 | 660 | 787 | 838 | 889 |
H | mm | 180 | 180 | 185 | 200 | 210 | 215 | 250 | 270 | 300 | 340 | 365 | 400 | 450 | 510 | 590 |
W | mm | 400 | 400 | 500 | 500 | 600 | 600 | 820 | 820 | 300 | 300 | 320 | 320 | 350 | 380 | 380 |
Weight | Kg | 14 | 16 | 18 | 20 | 24 | 29 | 35 | 47 | 91 | 129 | 210 | 320 | 660 | 920 | 1250 |
Dimensions |
Class 900Lb |
Size | inch | 1/2 | 3/4 | 1 | 1-1/4 | 1-1/2 | 2 | 2-1/2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 |
L-RF,BW | mm | 229 | 229 | 254 | 279 | 305 | 368 | 419 | 381 | 457 | 559 | 610 | 737 | 838 | 965 | 1029 |
H | mm | 180 | 180 | 185 | 200 | 210 | 215 | 250 | 270 | 300 | 340 | 365 | 400 | 450 | 510 | 590 |
W | mm | 400 | 400 | 500 | 500 | 600 | 600 | 820 | 820 | 300 | 300 | 320 | 320 | 350 | 380 | 380 |
Weight | Kg | 17 | 19 | 21 | 24 | 30 | 37 | 44 | 65 | 110 | 160 | 255 | 380 | 810 | 1050 | 1460 |
4" or above with worm gear
