1. Pressure rating: 2"~10" 150pls,
12" 100pls,
14" 16" 86 pls,
18" 72 pls,
20"~24" 51 pls
2. Low flow loss
The opening angle of the disc could be seen clearly throumg the position indicator.
Fast/ efficiemt operation for actomatic control system in a limited piping space.
Pneumatic actuator specification meets with ISO 5211, VDI/VDE 3845, DIN 3337.
NAMUR, easy to assemble solenoid valve, limit switshes and accesories.
Pmeumatic actuator max Air Supply pressure 8kg/cm
2 min air pressure 5kg/cm
2
3. Adjustable seat tightness
4. Easy to disassemble by handle
5. Less on-line down time forreplacement/maintenance
6. Actuator could be installed with inserted nut
7. Standard product is without nut
|
Type |
Size |
Material |
Seat |
O-ring |
Standard |
End type |
Dsic |
|
VP-830 |
2"-24" |
PVC |
EPDM,FPM |
EPDM,FPM |
ANSI,JIS.DIN |
Flanged |
PP |
|
VP-831 |
2"-24" |
CPVC |
EPDM,FPM |
EPDM,FPM |
ANSI,JIS.DIN |
Flanged |
CPVC |
|
VP-833 |
2"-24" |
PVDF |
EPDM,FPM |
EPDM,FPM |
ANSI,JIS.DIN |
Flanged |
PVDF |
|
VP-834 |
2"-24" |
PP |
EPDM,FPM |
EPDM,FPM |
ANSI,JIS.DIN |
Flanged |
PP |
|
NO |
PART |
MATERIAL |
|
1 |
BODY |
UPVC,PP,PVDF,CPVC |
|
2 |
DISC |
CPVC,PP,PVDF |
|
3 |
SEAT SEAL |
EPDM,FPM |
|
4 |
STEM |
SUS410 |
|
5 |
O-RING |
EPDM,FPM |
|
6 |
O-RING |
EPDM,FPM |
|
7 |
PENUMATIC ACTUATORS
ALUMINIUM ALLOY |
EXTRUDED |
|
8 |
BOLT&WASHER |
SUS |
|
9 |
PIN |
SUS |
