Strength testing pressure: PT 3.8, 6, 9, 6
Set testing pressure: 0.6
Seat testing pressure; 2.8, 4.4, 7.04
Applicable mcdia:
Water. Oil. Steam25C Q11F- 40C
Nitric acid 25P Q11F- 40P
Acetic acid 25R Q11F- 40R
Valve body: WCB
Applicable temperatrue: -40~180C
|
Main outer size |
|
DN |
G |
B |
L |
E |
H |
A |
|
6 |
1/4" |
5 |
50 |
15 |
28 |
25 |
|
10 |
3/8" |
8 |
50 |
15 |
30 |
65 |
|
15 |
1/2" |
95 |
56 |
17 |
34 |
85 |
|
25 |
3/4" |
12.5 |
60 |
18 |
40 |
95 |
|
25 |
1" |
16 |
71 |
20 |
52 |
110 |
|
32 |
11/2" |
20 |
78 |
21.5 |
62 |
140 |
|
40 |
11/4" |
25 |
96 |
23 |
68 |
140 |
|
50 |
2" |
32 |
101 |
24.5 |
75 |
155 |
|
65 |
21/2" |
40 |
120 |
25 |
82 |
180 |
|
