Diaphragm valve with an arcuate weir installed to the centre of the body.
The body and diaphragm are availabele in various types of material giving you the choice of a most suitable materials to this fluid composition.
|
nominal diameter |
inlet |
outlet |
|
DN 25-600 mm / 1" -24" |
DN 50-2500 / 2" -100" |
|
nominal pressure |
PN 25-630 / Ansi 150-4000 lb/sq. in |
/ |
|
material |
1.0460 - 1.5415 - 1.7335 - 1.7380 - 1.4903 - 1.4901 - 1.0619 - 1.5419 - 1.7357 - 1.7379 - 1.7706 - 1.4931 - C12A - 1: 6368 |
|
piping connection |
welding ends or flanges in all designs possible |
|
characteristic |
equal percent / linear / customer-specific |
|
pressure reduction |
single-stage / multiple-stage (controllable across all stages) |
|
body |
globe-, angle-, or Z-Type in casting or forged material |
|
actuator |
hydraulic - pneumatic - electric |
