Product Features
* 5 ports solenoid valve 4A100 series;
* 4A110, 4A120, 4A130C, 4A130E, 4A130P series solenoid valve;
* Internally piloted action, 5 port 2 position or 5 port 3 position;
* Grommet or DIN electrical connector;
* Body: Black anodization, hand anodization, natural anodization
* Port size: M5, 1/8"',;
|
Model |
4V110-M5 |
4V120-M5 |
4V130C-M5 |
4V130E-M5 |
4V130P-M5 |
4V110-06 |
4V120-06 |
4V130C-06 |
4V130E-06 |
4V130P-06 |
|
|
4A110-M5 |
4A120-M5 |
4A130C-M5 |
4A130E-M5 |
4A130P-M5 |
4A110-06 |
4A120-06 |
4A130C-06 |
4A130E-06 |
4A130P-06 |
|
Position and Way Number |
Two-position Five-way |
Three-position Five-way |
Two-position Five-way |
Three-position Five-way |
|
Effective Sectional Area |
5.5MM 2 (CV=0.31) |
5mm 2 (CV=0.28) |
12mm 2 (CV=0.67) |
9MM 2 (CV=0.5) |
|
Joint Pipe Bore |
Air inlet=Air outlet=Exhaust=M5" |
Air inlet=Air outlet=Exhaust=G1/8" |
|
Working medium |
40 Micron Filtered Air |
|
Motion Pressure |
Inner Guide Type |
|
Working Pressure |
0.15~0.8Mpa |
|
Max. Pressure Resistance |
1.2Mpa |
|
Operating Temperature |
"-5~60 degree centigrade |
|
Voltage Range |
±10% |
|
Power Consumption |
AC:3.0VA DC:2.5W |
|
Insulatiojn&Protection Class |
F Class.IP65 |
|
Wiring Form |
Lead Wire or Connector Type |
|
Highest Action Frequency |
5 Cycle/Sec |
|
Shortest Excitation Time |
0.05 Second |
Company name: Ningbo Huaqiu Industry and Trade Co., Ltd.
Established Year: 2006
History in Pneumatic: 5 years
Main Products:
A. Pneumatic components, like Pneumatic Cylinder, Solenoid Valves, pneumatic valves, FRLs, Pneumatic fittings and Hoses, muffler, etc.
B. Hydraulic valve
Management System: ISO9001
Advantage: Strong Technical design ability, Stable quality, and large production capability
Brand: JINTAI(international), JINTAI(China market)
Huaqiu is now supply to more than 40 countries and enjoying high reputation among all of our customers.
We're sure with both our hard work we'll enjoy common successful future in your local market.
