CE approved
Long time of warranty
Machine casing: spray coating metal plate
Function: Production of hot water
Host machine color: grey and white
Accessories: LCD controller, pressurized water tank(150L, 200L, 300L, 500L)
Safety protecting system:
1)High and low pressure protection
2)Anti-freeze protection
3)High temperature protection
4)Safety valve
5)Overload protection
6)Reverse phase
7)Lack of phase
8)Separation of water and electricity
Refrigerant: R22/R410A/R417a
| Home use heat pump |
|
| Modle | CKXRS-3.5IH | CKXRS-5.0IH | CKXRS-7.0IH | CKXRS-9.0IH |
| Rated Heating output(kw) | 3.5 | 5 | 7 | 9 |
| Rated produce hot water capacity(L/H) | 75 | 107 | 150 | 193 |
| Rated outlet hot water temperature | 55 |
| Maxi outlet hot water temperature | 60 |
| Electrical equipment parameter | rated power(kw) | 0.9 | 1.24 | 1.71 | 2.26 |
| rated current(A) | 4.1 | 5.6 | 7.8 | 10.3 |
| maxi power(kw) | 1.25 | 1.58 | 2.25 | 2.72 |
| maxi current(A) | 5.7 | 7.2 | 10.3 | 12.4 |
| Noise DB(A) | ≤ 50 | ≤ 53 |
| Weight(kg) | 40 | 60 | 67 | 72 |
| Refrigerant(g) | 800 | 1100 | 1300 | 1600 |
| Unit dimensions(mm) | 950x360x560 | 1010x360x630 |
| Power | 220V~/50HZ |
| Water tank | 150L/200L/300L/500L |
| Pipe size(mm) | 2xDN15 | 2xDN20 |
| Suitable environment temperature | -15~45 |
Zhejiang Cen New Energy Technology Co., Ltd. Our company is still developing more styles of products. We take the technology as the core\regard the quality as life\treat the user as god. We dedicated to provide you with the highest cost-effective energy-saving products\high-quality engineering design and meticulous transformation of after-sales service!
Our main products as follows:
Air-source heat pump unit for household and commercial
Ground source heat pump unit
Water source heat pump unit
Combine cooling\heating and hot water heat pump unit
Swimming pool heat pump unit
Heat recovery of centre air-conditioner so on energy-saving products, our products passed prove ISO9001\CCC\CE certificate.
Product features: Reasonable structure\stable quality\reliable and nice.
We consistently insist on the sane business strategy. We don't demand the biggest, only best. Take the most serious attitude, do the most professional thing. Let us enhance friendship with large clients and sincere cooperation, create brilliance!
