API 6D Cast Steel Butterfly Valve with Bare Shaft

API 6D Cast Steel Butterfly Valve with Bare Shaft
Price: US $ 49-199/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Paypal
The pipeline butterfly valve apply to many liquid and gas pipelines, and are up to the standard of AWWA, widely used in power station, civic engineering water supply system.
The valves possess properties as follows:
1. Possessing properties of good cutting off and adjusting, it can reach the sealing of air bubble level.
2. Fixable seat of machine can fully adjusts, can adjust and exchange seat in site, needn't especial tools, haven't to disassemble valve.
3. Open-close moment is minor, service life is long.
4. Valve can install in horizontal or vertical place.

1) Standards:
A) Manufacture: GB12238, JB/T8527, API609
B) Face to face/end to end dimensions: ANSI B16.10, GB12221
C) Pipe flange: JB/T74 90, GB12380, HG20615~20635, SH3006, ANSI B16.5
D) Testing and inspection: GB/T13927, API598
2) Body materials: CI, DI, WCB, SS Disc: DI, SS304, SS316,
Aluminum Bronze Split Stem: WCB, SS416, SS304, SS316
3) Flange drilling: DIN PN10/PN16 BS4504, BS 10D/E ISO2084, ISO2531 ANSI 125/150, AS2129 ASA125/150 JIS 5K/10K
4) Nominal Diameter: DN500~1400.
5) Actuator: Electric
6) The product is 1.6Mpa pressure level, valve body made up ductile iron.

Nominal pressure (MPa)1.6
Testing PressureBody shell2.4
Working pressure (MPa)1.6
Suitable temperature (°C)≤80
Suitable MediumWater

Prod Model: FYV
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Actutor: Electric
Nominal Diameter: Dn500~1400
Ends Con,: Rtj,RF,Sw,Bw
O-Ring Sealing: PTFE,NBR,Rptfe
Connection Form: Flange
Work Pressure: High Pressure (',10.0mpa< Pn <80.0mpa)
Structure: Centre Sealing
Seal Form: Force Sealed
Working Temperature: Normal Temperature (',-40??C
Application: Industrial Usage
Material Of Seal Surface: Metal Hard Sealed
Fangyuan Valve Group Co. Ltd, seated at Wuxing Industrial Zone, Oubei, Yongjia County, so called as "Pump & Valve Village of China", close to the national scenic spot Nanxijiang River to the east and facing the downtown of Wenzhou City to the south, and established in 1998 with the former as Zhejiang Fangyuan Valve Manufacturing Co. Ltd, has got a great achievement via hard work and continual going forth ahead and become a magnate of plate gate valve from an unknown small enterprise and leads the future of this industry. Fangyuan Valve Group Co. Ltd was derived from Zhejiang Fangyuan Valve Manufacturing Co. Ltd in 2005 and holds 5 stock subsidiaries, three production bases in Wenzhou, Shanghai and Lishui and a cast base in Lishui, a total registered capital up to 4, 000, 000 USD, a total land area 110000m2, over 600 staff members, 60 of which are technicians, a digital process center and more than 350 sets of various middle and large equipments and an annual output up to 12000 tons.

This Group comes as a key enterprise among the said"Pump & Valve Village of China"and a well known enterprise in the national valve industry and specializes in the production of plate gate valve, gas valve, electric station valve etc., with the development, design and invention patent know-how up to the advanced technical level of the world and the leading level of the nation and some of the products used to replace the imported ones. This Group has been accredited to ISO9001, API6A/6D, CE, AZ etc., won the first prize of scientific advance of Zhejiang Province and elected as a member of the first-grade supply network of China Petroleum, a member of China Petrochemical Resource Market, a member of No. 1 Energy Network, a member for supply of the national electric power system, an appointed production enterprise by Chemical Equipment General Corp., a Wenzhou high-tech enterprise, a start enterprise of Yongjia County, one of the 30 powerful enterprises among the said village and a banking credit AAA grade enterprise in the successive recent years. It holds a powerful strength in the technical, management and market etc. Respects and a notable superiority in the severe market competition.

The products, approved by the nation and province early or late, have been elected as quality products of Zhejiang Province and well-known ones of Wenzhou. This Group follows the guide policy of"takeing people as the base, managing the company with laws, prospecting the enterprise with quality, continuing innovations"and makes the products well sold to all over the country and USA, Canada, the Middle East, Europe etc. World markets, greatly favored by the users therein. Therefore a solid basis has been made for the further open-up of the world market, for the making of Fangyuan brand, for the national industrial progression and for the great target to create a valve magnate of China and step forward to the 50 powerful valve companies of the world.

Slab gate valve: Slab gate and expanding gate, double sealed upstream and downstream design, double block and bleed open and closed design. Size: DN50~DN1400, pressure: PN16~PN420, handwheel, gear, electric, pneumatic.

Fully welded ball valve.

Forged steel valve. Material: A105, LF2, F11, F22, F5, F304, F316, F321 etc.
