Specifications
1.Reliable sealing surface
2.150LB-1500LB
3.face to face conform to ISO 5752
Capacity Pamameters:
Nominal Diameter
DN150~300
Nominal Pressure
1.0Mpa
1.6Mpa
Shell test pressure
1.5Mpa
2.4Mpa
Sealing test pressure
1.1Mpa
1.76Mpa
Main Parts material:
NO
Name
Material
1
Body,bonnet
Epoxy resin
2
Valve disc
Stainless with rubber cladded
3
Sealing gasket
NBR,EPDM,FPM
Working Temperature:
NBR≤80°C;
EPDM≤120°C
FPM ≤ 160°C
Executive Standard:
Design standard: AWWAAA508
Connecting Flange: GB/T17241.6-1998
Structure Length: GB12221-89
Test Standard: JB/T9092-1999
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
