These type of Valves are designed to provide different combination of Pilot Arrangements that can be used for various types of functions like: On/Off, Pressure Reducing, Pressure Relief, Flow Control, Pump Bypass, Non Return & many more.
MAIN FUNCTIONS: Automatic Control Pilot Operated Valves:
On-Off/ Pressure Reducing Pressure Relief / Pump Bypass / Safety of Line/ Flow Rate / Level Control-Overhead Tank & Vessels Level Control / Pressure Relief Cum Pressure Reducing / Non Return Function (Check Valve).
WIDELY USED FOR: Automatic Control Pilot Operated Valves:
Air Craft Fuel Injection / Defuelling Drip Irrigation. / Housing Colony Water Supply with Timer.
(Water Distribution System) / Water Tank Level Control /Musical & Dancing Fountain with Sequential Timer and Many More.
|
Product specifications |
1'' |
|
Medium pressure |
≥1.0MPa |
|
Circulation medium |
Fluid |
|
Rated voltage |
DC24V |
|
Working current |
≤50MA |
|
Open/close time |
≤5S |
|
Extra long time |
50000 times |
|
Body material |
Brass |
|
Actuator material |
Engineering Plastics |
|
Sealing material |
EPDM & PTFE |
|
Valve ball |
Nickel-plated brass / SS304/SS316(Optional) |
|
Actuator rotation |
90° |
|
Environment temperature |
-15~50 |
|
Liquid temperature |
2~90 |
|
Manual override |
Yes |
|
Line Control |
2 / 3 / 7 wiring (Optional) |
Shanghai ThinkTank Process Management Co., Ltd. is the sole production and R&D institute of Taiwan STONE Company in Mainland China. ThinkTank entered Chinese market in 2002 and moved from Hangzhou to Shanghai headquarter in 2012. Based on over 30 years experience in researching and manufacturing automatic instruments, brining in overseas advanced technology and combining domestic users real working situation, ThinkTank is specialized in producing new typed self-regulating valves, control valves and various kinds of automatic instruments. ThinkTank's business includes engineering projects such as electricity, metallurgy, petrochemical processing, light industry and building materials, municipal water service and natural gas.
Enterprise history
1985.08 Taiwan STONE company was established in Taipei city.
1990.02 Sales network covered Southeast Asia.
2002.06 Branch office was fund in Hangzhou, Zhejiang, handling all business in China
2012.10 Mainland head office was moved to Pudong, Shanghai
Shanghai ThinkTank Process Management Co., Ltd. Has a professional team works for control valves design and engineering application. ThinkTank develops a series of hi-tech products after absorbing overseas advanced technology and innovating.
*New self-regulating, micro pressure, differential pressure, flow, temperature control valve
*New pneumatic (electric) linear actuator (low dB, high pressure) control valve
*Pneumatic (electric) rotary actuator (O/V ball, butterfly) control valve
*Pneumatic (electric) special corrosion resisting control valve
Shanghai ThinkTank Process Management Co., Ltd sticks to the policy of "client oriented, quality comes first, and faith is root". Depending on many years experience on engineering application in various industries, ThinkTank provide clients with good, reliable full service, focusing on maximizing the rate of return on investment for clients.
