Feature:
Size | DN40-DN1200 |
End flange | ANSI B 16.1, EN 1092, AS 2129 |
Face to face | ANSI B 16.10 |
Top flange | ISO 5211 |
Normal pressure | DN40-DN600 PN1.0/1.6MPa (150/200PSI) DN700-DN1200 PN1.0MPa (150PSI) |
Body | CI/DI/WCB/ALB/CF8/CF8M |
Disc | DI/ALB/Rubber lined Disc / 1.2501/CF8M/1.4529/CF8/Hastelloy |
Stem | 416/304/316/431/17-4PH |
Seat | NR/Hypalon/EPDM/Neoprene/NBR/Wear-Resistant EPDM/Viton/Silicon/Heat-Resistant EPDM/White NBR/White EPDM/EPDM /PTFE |
Temprature | -45c~150c |
Feature | Small in size, light in weight and easy maintenance, it can be used as a device to cut-off or regulate |
Apply | Fresh water, sewage, sea water, air, vapor, food, medicine, oils. acids, alkalis, salt etc. |
advantages
1. Small in size and light in weight, easy instillation and maintenance. It can be mounted wherever needed
2. Simple and compact construction, quick 90 degrees on-off operation
3. Minimized operating torque, energy saving
4. Flow curve teeing to straight line, excellent regulation performance
5. Long service life, standing the test of tens of thousands opening/closing operations
6. Bubbles-tight sealing with no leakage under the pressure test
7. Wide selection of materials, applicable to various mediums
8.Various of rubber seats, such as Natural Rubber, Hypalon, EPDM, Neoprene, NBR, Viton, PTFE, Polyurethane.etc.
9.We can provide various of flange end standards, such as DIN2501, ANSI125/150, AS2129 Table D & E, BS4504,BS10D&E,JIS10K.
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
