Components
1 Body Cast iron or ductile iron
2 Disc Cast iron or ductile iron
3 Seat Brass
4 Stem Carbon steel or stainless steel
5 Bonnet Cast iron or ductile iron
6 Hand wheel Cast iron or ductile iron
Application
1 Design according to DIN3202-F32
2 Flange end DIN2532/2533
3 Nominal Pressure PN10/PN16
Test
Working Pressure: PN10/PN16
Test Pressure Shell: 15bars/24bars
Seat 11bars/17.6bars
Wenzhou Better Valve Co., Ltd. Was established in 2007, integrating the design, production, examination with sales into a body in the field of valve industry.
BETTER VALVE is also equipped with the test lab with examination equipment for material chemical composition analysis, physical property and non-destructive examinations such as RT, UT, MT, and PT.
