1,Specifications
1.Face to Face:DIN3202 F4
2.Flange:DIN2501
3.size:DN40-DN300
4.material:GG25
5.CE ISO 9001
available medium:water,petroleum products
working temperature:≤120oC
face to face:DIN3202 F4
flange:DIN2501.
2,Prduct Description
Gate Valve: ANSI gate valve, BS gate valve, DIN 3352 gate valve, JIS gate valve, cast iron gate valve, rising stem gate valve, non-rising stem gate valve, flange end gate valve, metal seated gate valve, resilient seta gate valve
Flange End Non-Rising Stem Metal Seated Gate Valve-DIN3352
Body: Cast iron DIN1691
Wedge: Cast iron DIN1691
Bonnet: Cast iron DIN1691
Handwheel: Cast iron DIN1691
Seat Ring: Cast Bronze DIN1705
Wedge Face Ring: Cast Bronze DIN1705
Stem: Stainless steel DIN17224
Cast iron valves
Type: Butterfly valves, Gate valves, Check valves, Global valves, Y strainer
Size: DN40-1200 or 1.5-48' or above
Working Pressure: PN10/16/20/25, 150LB-2500LB
Suitable temperature: -45c~150c
Standard:
(1)Design and manufacture: DIN3352, BS5163, BS5150, ANSI B16.34, API600, API6D, API609, EN593, GB, T12238
(2)End connection: ANSI B 16.1, ASME B16.5, B16.47, B16.25, B16.34, JISB2212-JISB2214, DIN2543-2550, EN1092, AS2129, ISO 5211
(3)Wall thickness: API600, BS1868
(4)Face to face (end to end): EN 558, ASME B16.10, DIN3202, ISO5752, JIS, API609, MSS, BS5155
(5)Inspection and test: API598, EN12266-1, BS6755, API6D, ISO5208
Materialfor main parts:
(1)Body: CI, DI, WCB, ALB, CF8, CF8M
(2)Disc: DI, ALB, C95400, Rubber lined Disc, 1.2501, 1.4529, CF8M, CF8, Hastelloy
(3)Stem: SS416, SS410, SS304, SS431
(4)Seat: NR, Hypalon, EPDM, Neoprene, NBR, Wear-Resistant EPDM, Viton, Silicon, Heat-Resistant EPDM, WhiteNBR, WhiteEPDM, EPDM, PTFE
Coating: Fusion bonded epoxy coated
Connection type: Flanged type, Push-on type, Mechanical Joint type, Plain ends type
Sealing: Soft sealing or metal-to-metal seat, Flexible graphite
Operation: Manual, Pheunatic, Electric, Hydraulic and Pnewmatic-Hydraul
Appropriate medium: Air, water, sewage, steam, coal gas, oil
Packaging: Export polywood cases, or as per customers' requirements
Delivery Time: 25 days after order conformed
Payment: By T/T or L/C
Application: Fresh water, sewage, sea water, air, vapor, food, medicine, oils. Acids, alkalis, salt etc.
3,Product picture.
|
Nominal pressure |
1.6Mpa |
|
Seat test pressure |
1.6Mpa |
|
Shell Test Pressure |
2.4Mpa |
|
Suitable Temperature |
≤230C |
|
Suitable Media |
water,Oil,gas |
|
EVK FITTING GROUP Co., Ltd (China) is a leading group, engaged in manufacturing valve, pipe fitting and flange, affilicating Qingdao EVK Industrial Co., Ltd, Yantai EVK Valve Manufacturing Co., Ltd, Hebei EVK Pipe Fitting Co., Ltd and Tianjin EVK Flange Fabrication Co., Ltd. EVK Group has more than 2000 staffs and covers around 150000 square meters totally.
Main production includes:
Valve: Cast iron/Ductile iron/Cast steel/Forged steel Valve( DIN3352 Resilient seated F4/F5 Gate valve, DIN3352 F4/F5 metal seated Gate valve, BS5163/BS5150/AWWA C509 Gate valve, API600 Gate valve, Wafer/Lug/Double flange butterfly valve, DIN/MSS Globe valve, Wafer/swing check valve, Y-strainer, JIS marine valve)
Pipe fitting: Carbon steel butt welding pipe fitting(Elbow, Straight and reducing tee, concentric and eccentric reducer, cap), Forged steel pipe fitting(Elbow, Tee, Reducer), Malleable iron pipe fitting.
Flange: Carbon steel and stainless steel forged flange(Flat flange, welding neck flange, slip on flange, blind flange).
Autoparts: Brake shoes, Brake pads, Brake discs, Brake drums.
We exported to more than 25 countries in the world, our main customers have CRANE, WALWORTH, OARI, etc. Our company was awarded with ISO9001 certificate and CE for our valve, pipe fitting and flange products.
Our blief is "Do friend first, Do business second", we welcome all friends from all over the world to do business together!
