Key Specifications/Special Features:
Size: 2 to 24-inch wafer type, lug type and double flanged type
Materials:
Body: Ductile iron, carbon steel, 304 and 316 stainless steel and aluminum bronze
Disc: Ni-plated ductile iron, 316 stainless steel and aluminum bronze
Shaft: Stainless steel 416, 316 stainless steel, MONEL and 17-4pH
Seat: EPDM, NBR, VITON and PTFE
Bushing: PTFE
Working pressure:
2 to 14-inch: 40bar
16 to 24-inch: 25bar
APC Industries, a leading manufacturer specialized in industrial valves and Marine valves. It was established in 1999. APC main products is butterfly valves for industry application ( wafer type butterfly valve, Lug type butterfly valve, Double flanged butterfly valve, rubber-coated butterfly valve), Double Eccentric Butterfly Valves and Tri-Eccentric butterfly valve for Marine application, and these High performance butterfly valve has gain the Monopoly in China. API Check valve, API Gate valve, API Ball valve for oil and gas application. Y-strainer, Electric Actuators and pipe fittings.
Now we have gained the ISO 9001: 2000 International Quality Systems, Europe's PED/ CE marked product, Germany' S Pressure Equipment Ordinance TRD100/WO, Norwegian DNV Classification Society Factory and many classification societies such as CCS, British LR Certificates, API 6D /607 Certificates, and FM/UL Certificates for fire fighting valves.
The company carries out the design, manufacture and testing of valves according to the international standards such as ANSI. DIN. BS, JIS.
Warmly welcome to visit our factory.
