APPLICABLE STANDARDS:
Design:ASME B16.34,API 608
End Flange :ASME B16.34,CLASS 400
Pipe Thread : ASME B1.20.1,BS21 DIN2999/259 ,BSP ISO 7/1,ISO 228/1 JIS B 0203
Butt Weld : ASME B 16.25 φB2 Available in Sch 10, 20&40
Socket Weld : ASME B 16.11
Flange End : ASME B 16.5 DIN 2542-2545 JIS B2238
SPECIFICATIONS:
Working Pressure :1000psig at 100°F(38 °C)
Temperature Range:-30°F to 350°F(-34 °C to 177 °C)
|
Diameter |
|
Size(mm) |
|
mm |
inch |
PN |
D |
L |
H1 |
Double acting pneumatic |
Single acting pneumatic |
Electric |
|
H2 |
A1 |
H2 |
A2 |
H2 |
A3 |
|
15 |
1/2 |
16/25 |
15 |
72 |
40 |
136 |
145 |
155 |
195 |
145 |
72 |
|
20 |
3/4 |
16/25 |
20 |
82 |
46 |
142 |
145 |
161 |
195 |
151 |
72 |
|
25 |
1 |
16/25 |
25 |
90 |
57 |
172.0 |
158 |
194.0 |
217 |
181.5 |
160 |
|
32 |
1-1/4 |
16/25 |
31.8 |
112 |
64 |
179.0 |
158 |
201.0 |
217 |
188.5 |
160 |
|
40 |
1-1/2 |
16/25 |
38.1 |
120 |
71 |
208.0 |
177 |
218.0 |
258 |
195.5 |
160 |
|
50 |
2 |
16/25 |
50 |
145 |
81.5 |
218.5 |
177 |
228.5 |
258 |
206 |
160 |
|
65 |
2-1/2 |
16/25 |
65 |
185 |
95 |
242.0 |
196 |
260.0 |
299 |
253 |
196 |
|
80 |
3 |
16/25 |
80 |
210 |
109 |
274.0 |
225 |
291.0 |
348.5 |
267 |
196 |
|
100 |
4 |
16/25 |
100 |
266 |
142 |
324.0 |
273 |
341.0 |
397 |
338 |
255 |
