Electric Submersible Water Pump (CE Approved)
| Price: |
Negotiable |
| Min Order: |
1 |
Basic Info.
Model NO.:WQD6-16, V450, V750, V1100
Application:Sewage Pump
Type:Blade Pump
Material:Stainless Steel
Power:Electric
Structure:Single-stage Pump
Theory:Centrifugal Pump
Outside:1.5"-2"
Export Markets:GlobalAdditional Info.
Trademark:FLORANK
Packing:Carton
Standard:CE
Origin:Taizhou, Zhejiang
Production Capacity:80000PCS /YearProduct Description
Professional Sewage Pump with CE Certificate
Working Conditon
Max. Submerged depth: 5m
Fluid temperature up to +40C
Max ambient temperature +40C
Applicaton&Feature
The pumps are designed for draining dirty water, waste
Water and sewage in domestic and civil application.
Being equipped with a half-open impeller, the pumps
Are allowed to pump liquids containing suspended
Solids up to Φ 45mm and short fibres. The pumps are outstanding in the reliability with automatic
Float switch and builded in over-load protector.
Component Material
Pump body: Cast iron
Motor bracket: Stainless steel
Impeller: Cast iron
Motor shaft: CS45# or SS
Mechanical seal: Ceramic-graphite or silicon carbide-carbide alloy
Motor Information
Single phase two-pole induction motor
220V, 50Hz, 60Hz 110V/60Hz
Thermal over load protector, continuous duty.
Insulation calss: E
Protection: IP X8| Model | Power | Outlet | Max. Flow | Max Head | Dim | G.W |
| single phase | Kw | Hp | inch | L/min | m | mm | kg |
| V180F | 0.18 | 0.2 | 11/2" | 133 | 7 | 220x180x450 | 12 |
| V250F | 0.25 | 0.35 | 11/2" | 150 | 7.5 | 240x180x450 | 14 |
| V450F | 0.45 | 0.55 | 2" | 290 | 8.5 | 260x200x500 | 18 |
| V750F | 0.75 | 1 | 2" | 300 | 12 | 260x200x550 | 20 |
| V1100DF | 1.1 | 1.5 | 2" | 360 | 13 | 280x220x560 | 22 |
| V1500DF | 1.5 | 2 | 2" | 500 | 16 | 525x235x295 | 24 |
| V2200DF | 2.2 | 3 | 2" | 600 | 20 | 540x240x320 | 26 |
| V750FS | 0.75 | 1 | 2" | 300 | 12 | 260x200x550 | 19 |
| V1100FS | 1.1 | 1.5 | 2" | 360 | 13 | 280x220x560 | 21 |
| V1500FS | 1.5 | 2 | 2" | 500 | 16 | 525x235x295 | 23 |
| V2200FS | 2.2 | 3 | 2" | 600 | 20 | 540x240x320 | 25 |
