DESIGN FEATUES:
Compactness and beauty of structure
Light and easy installation
Corrosion resistance ,wide use
Sanitation and nontoxicity of material
Abrasion resistance ,easy take-down and maintenance
APPLICABLE STANDARDS:
DESIGN:ANSI JIS DIN GB
Working Pressure :0.6-1.0MPa
Temperature Range:32°F to 140°F(0°C to 60°C)
|
Diameter |
Size(mm) |
|
mm |
inch |
D |
L |
H1 |
Double acting pneumatic |
Single acting pneumatic |
Electric |
|
H2 |
A1 |
H2 |
A2 |
H2 |
A3 |
|
15 |
1/2 |
13 |
112 |
45 |
96 |
145 |
96 |
163 |
105 |
72 |
|
20 |
3/4 |
18 |
132 |
55 |
96 |
145 |
96 |
163 |
105 |
72 |
|
25 |
1 |
23 |
144 |
66 |
96 |
145 |
96 |
163 |
105 |
72 |
|
32 |
1-1/4 |
30 |
167 |
82 |
96 |
145 |
115 |
195 |
105 |
72 |
|
40 |
1-1/2 |
38 |
172 |
98 |
96 |
145 |
115 |
195 |
105 |
72 |
|
50 |
2 |
48 |
206 |
120 |
115 |
158 |
115 |
195 |
102.5 |
160 |
|
65 |
2-1/2 |
61 |
273 |
140 |
115 |
158 |
137 |
217 |
102.5 |
160 |
|
80 |
3 |
69 |
303 |
163 |
115 |
158 |
137 |
217 |
102.5 |
160 |
|
100 |
4 |
99 |
333 |
225 |
137 |
177 |
147 |
258 |
126 |
196 |
