The model TD thermostatic expansion valve is a kind of thermostatic expansion valve with fixed valve port for automaticly supplying and regulating the refrigerant, which is suitable for small scale refrigeration system.
The powerhead is laser welded for long life.
Superheat (3.5K) is fixed.
ODF copper tube welding. (valve body with 30% silver brazing. )
Suitable for Freon and hydrocarbons.
Maximum working pressure: 2.8 MPa.
Model |
Nominal capacity (kw) | Type of equalization |
Connection size |
R134a |
R22 |
TD-1 |
0.8 |
1.1 |
Internal equalizated |
ODF Inlet
:1/4
Outlet
:1/2 |
TD-2 |
1.6 |
2.8 |
TD-3 |
2.1 |
3.0 |
TD-4 |
3.1 |
4.4 |
TD-5 |
3.7 |
5.3 |
