| Price: | US $ 28/Set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T |
2-pc design as per ASME B16.34
Full bore
Size: 1/4" ~ 4" ( DN8 ~ DN100)
Pressure: PN16/25/40/64, 1000PSI
Threaded end could be NPT, BSP, etc.
optional for lockable level
optional for both threaded and socket welded.
Maaterial list:
No | Part Name | Materials |
1 | Body | A105/A182-F304, F316(L) |
2 | Ball | A105/A182-F304, F316(L) |
3 | Stem | A105/A182-F304, F316(L) |
4 | Seat | PTFE/RPTFE/Nylon/PEEK |
5 | Gasket | PTFE/Graphite |
6 | Packing | PTFE/Graphite |
7 | Thrust Washer | PTFE |
8 | Stop Plate | Stainless Steel |
9 | Lever | Carbon Steel Galvanized |
10 | Stem Nut | Stainless Steel |
11 | Stop Pin | Stainless Steel |
12 | Stud Bolt | A193-B7(M), B8(M) |
Reduced Bore | Full Bore | L | d | NPT | SW | L1 | H | W | Weight | |||
RB | FB | RB | FB | RB | FB | |||||||
3/8"x1/4" | 1/4" | 68 | 10 | 3/8" | 1/4" | 17.6 | 14.2 | 9.6 | 9.6 | 53 | 130 | 1.1 |
1/2"x3/8" | 3/8" | 68 | 10 | 1/2" | 3/8" | 21.8 | 17.6 | 9.6 | 9.6 | 53 | 130 | 1.1 |
3/4"x1/2" | 1/2" | 73 | 13 | 3/4" | 1/2" | 27.1 | 21.8 | 12.7 | 9.6 | 56 | 130 | 1.3 |
1"x3/4" | 3/4" | 97 | 18 | 1" | 3/4" | 33.8 | 27.1 | 12.7 | 12.7 | 70 | 160 | 2.1 |
1-1/4"x1" | 1" | 105 | 24 | 1-1/4" | 1" | 42.6 | 33.8 | 12.7 | 12.7 | 80 | 220 | 3.4 |
1-1/2"x1-1/4" | 1-1/4" | 118 | 30 | 1-1/2" | 1-1/4" | 48.7 | 42.6 | 12.7 | 12.7 | 90 | 250 | 4.1 |
2"x1-1/2" | 1-1/2" | 133 | 38 | 2" | 1-1/2" | 61.2 | 48.7 | 15.9 | 12.7 | 100 | 250 | 6.2 |
2-1/2"x2" | 2" | 148 | 48 | 2-1/2" | 2" | 74.1 | 61.2 | 15.9 | 15.9 | 110 | 290 | 9.5 |
| Prod Model: | Q11F, Q61F |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Design And Manufacture: | Asme B16.34 |
| Face To Face: | DIN 3202 M4 |
| Threaded End: | ANSI B1.20.1 |
| Fire-Safe: | API 607,API 6fa |
| Test And Inspection: | API 598 |
| Connection Form: | Flange |
| Channel: | Straight Through Type |
| Structure: | Floating Ball Valve |
| Type: | Floating Ball Valve |
| Application: | Household Usage |
| Material: | F304,F316,F321,F51 |
