1. Steam Globe Valve Material:
* ASTM A216 WCB
A351 CF8, CF8M, CF3, CF3M, CF3MN, CN7M
A890 4A
A352 LCB
SUS 904L
Titanium
Hastelloy alloy
Monel alloy
2. Steam Globe Valve Pressure rating and size:
* 150# ,300#,600# : 1/2"~16",DN15~DN400
* 900# : 2"~10", DN50~DN250
* 1500# : 2"~8", DN50~DN200
* 2500# : 2"~6" ,DN50~DN150
3. Steam Globe Valve Features:
* Design - API 600/BS 1414/ISO 10434/DIN 3352
* Face to Face & End to End - ASME B16.10/ISO 5752/BS 2080/DIN 3202
* Flanged Ends - ASME B16.10/ISO 5752/BS 2080/DIN 3202
* Butt-Weld Ends - ASME B 16.25
* Fire Safe - API 607/ API 6FA
* Test - API 598
4. Steam Globe Valve Applications:
* Chemical, Petrochemical, Oil & Gas, Power Plant, General Industry etc.
5. Steam Globe Valve Structure:
* BB : bolt bonnet
* OS & Y : outside screw and yoke
6. Steam Globe Valve Temperature rating:
* -45°C - + 650 °C or above
7. Steam Globe Valve Operators and option:
* Pneumatic / Electric/ Gear box/ Locking Device/ Handwheel etc.
8. Steam Globe Valve Certificates :
* API 6D, API 6FA, CE, ISO 9001
9. Steam Globe Valve The main material to choose from :
Body | WCB | CF8 | CF8M | Monel |
Wedge Disc | WCB | CF8 | CF8M | Monel |
Stem | F6a | F304 | F316 | Monel |
Wedge Disc Sealing Face | 13Cr | 13Cr | STL | 304 | STL | 316 | STL | Monel |
Body Sealing Face | 13Cr | STL | STL | 304 | STL | 316 | STL | Monel |
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
