Features & Specifications
Design & Manufacture: API 602
Constructions: OS&Y Construction, Bolted Bonnet, Welded Bonnet &
Pressure Sealed Bonnet
Back-seating, Renewable Seat Ring
Full Port / Conventional Port
Size Range: 1/4" to 4"N. B.
Pressure Ratings: ANSI 800, 900, 1500 & 2500
End Connections: Threaded, Flanged, Buttweld, Socket Weld, Hub Connectors, Compact Flange or other proprietary connections.
Materials Available in: A105, F304, F316 or Equivalent, Available also in low temperature steels, low alloy steels, stainless steels, duplex type stainless steels and other exotic materials; Various trim materials available to suit service conditions
Various trim materials are available to suit different service conditions
Actuations: Manual
To MR 0175 and MR 103 on request
Since 1989, Sino Valve has dedicated itself to manufacture a wide range of industrial valves for the services of Oil, Gas, Refinery, Chemical, Marine, Power Station. 90% of our valves are OEM for European and United State valve brand, so top quality can be assured with competitive price.
