Hydraulic valves-flow control valves Deceleration valves/deceleration and check valves
Raypoo hydraulic valves-flow control valves Deceleration valves/deceleration and check valves are available either with or without an integral check valve which allows free reverse flow. Flow rate through the valve is regulated by the movement of the spool, which is operated by a cam. When the spool is depressed, the flow is decreased in normally open type valves and increased in normally closed type valves. Their principal use is to control the speed of actuators in machine tools andsimilar applications.
|
Deceleration valves/deceleration and check valves |
|
Specifications |
|
Model numbers |
Max.Flow L/min |
Max.Operating Pressure Mpa |
Approx. Mass kg |
|
Threaded connection |
Sub-plate Mounting |
Z*T |
Z*G |
|
ZT/ZCT-03-*-*-22/2280/2290 |
ZT/ZCT-03-*-*-22/2290 |
30 |
21 |
4.3 |
4.3 |
|
ZT/ZCT-06-*-*-22/2280/2290 |
ZT/ZCT-06-*-*-22/2290 |
80 |
8.7 |
8.7 |
|
ZT/ZCT-10-*-*-22/2280/2290 |
ZT/ZCT-10-*-*-22/2290 |
200 |
17 |
17 |
