JIS Globe Valve (J61)
| Price: |
Negotiable/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T |
Structure: Stop
Pressure: Low to high pressure
Power: Manual
Material: Casting
Temperature of Media: Normal Temperature
Media: Water
DETAILED PRODUCT DESCRIPTION
1) Sizes: 1/2''~48''
2) Class: 150~1, 500Lb
3) Material: WCB, LCB, CF8 304, CF8M 316, CF3 304L, CF3M 316L, WC1, WC6, WC9, CN7M, Monel
4) Stardards:
A) Design and Manufacture: BS 1873, ANSI B16.34
B) Face to Face and end to end: ANSI B16.10
C) End Flange dimensions: ANSI B16.5
D) BW end dimensions: ANSI B16.25
E) Socket-weld dimension: ANSI B16.11
5) Inspection and test: API598
|
Part name |
Carbon Steel to ASTM |
Alloy Steel to ASTM |
Stainless Steel to ASTM |
|
1 |
Body |
A216 WCB |
A352 LCB |
A217 WC1 |
A217 WC6 |
A217 WC9 |
A217 C5 |
A351 CF8 |
A351 CF8M |
A351 CF3 |
A351 CF3M |
|
9 |
Bonnet |
A216 WCB |
A352 LCB |
A217 WC1 |
A217 WC6 |
A217 WC9 |
A217 C5 |
A351 CF8 |
A351 CF8M |
A351 CF3 |
A351 CF3M |
|
6 |
Bolt |
A193 B7 |
A320 L7 |
A193 B7 |
A193 B16 |
A193 B16 |
A193 B16 |
A193 B8 |
A193 B8 |
A193 B8 |
A193 B8 |
|
5 |
Nut |
A194 2H |
A194 2H |
A194 2H |
A194 4 |
A194 4 |
A194 4 |
A194 8 |
A194 8 |
A194 8 |
A194 8 |
|
11 |
Gland |
A182 F6a |
A182 F6a |
A182 F6a |
A182 F6a |
A182 F6a |
A182 F6a |
304 |
316 |
304L |
316L |
|
12 |
Gland Flange |
A216 WCB |
A352 LCB |
A217 WC1 |
A217 WC6 |
A217 WC9 |
A217 C5 |
A351 CF8 |
A351 CF8M |
A351 CF3 |
A351 CF3M |
|
3 |
Disc |
A216 WCB |
A352 LCB |
A217 WC1 |
A217 WC6 |
A217 WC9 |
A217 C5 |
A351 CF8 |
A351 CF8M |
A351 CF3 |
A351 CF3M |
|
7 |
Gasket |
SS Spiral Wound W/graphite, or SS piral Wound W/PTEE, or Reinforced PTEE |
|
10 |
Packing |
Braoded graphite or Die-formed graphite ring or PTEE |
|
13 |
Stem Nut |
Copper Alloy or A439 D2 |
|
14 |
Hand Wheel |
Ductile Iron or Carbon Steel |
| Prod Model: |
J61 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Structure: |
Through Way Globe Valve |
| Stem Thread Position: |
Outside Screw Stem Globe Valve |
| Sealing Form: |
Gland Packings Globe Valve |
| Standard: |
ANSI |
Zhejiang Xinhai Valve Manufacturing Co., Ltd, located in Oubei, Wenzhou city, was established in 1986. with more than 20 years experience, our company now becomes a professional valve manufacturer by developing, manufacturing, marketing and servicing. And it covers an area of 10, 000 square meters and has two subsidiary factories.
Our product includes gate, check, globe, ball, butterfly, plug, strainer and other valve. The valves are manufactured according to ANSI, API, DIN, GOST, BS, JIS, Chinese GB standers and the customers' requirements. These products have been installed throughout the world, having a wide variety of applications in the Gas, Oil, Refining, Chemical, Marine, Power Generation and Pipeline Transmission Industries.
Pressure range: Class125-Class2500, PN6-PN420
Size range: NPS1/2-NPS48
Operation type: Manual, gearbox, chain wheel, pneumatic, electronic, etc
Connection End: Flanged, BW, SW, NPT, wafertype, etc.
Materials(casting): WCB, WCC, LCB, LCC, LC1-3, CF8, CF3, CF8M, CF3M, CF8C, CN7M, CA15, C5, WC5, WC6, WC9, Monel, etc.
In order to introduce the international quality management system, Xinhai have got the approval o ISO 9001, API-6D, CE and Chinese TSG certification. Also, Xinhai established a multi-functionl phys-chemical lab to futher supervise the quelity time to time and fittde out spectrum analyzer, portable spectrograph(PMI), impact tester, hardness meter, tensile tester, thickness meter, magnetic particle tester, gugitive emission tester and NDE testing equipment.
The main target of Xinhai is to offer a high quality products and service to ensure the highest degree of satisfication and fidelity of our customers. Welcome the new and old customers to cooperate with Xinhai to explore wider global markets and create more brilliant future together!
