Quick Details
Standard or Nonstandard: |
Standard |
Structure: |
Butterfly |
Pressure: |
Low Pressure |
Power: |
Manual |
Material: |
Casting |
Temperature of Media: |
Medium Temperature |
Media: |
Water |
Port Size: |
DN40-DN1500 |
Place of Origin: |
Hebei, China (Mainland) |
Model Number: |
wafer valve |
Brand Name: |
LIQIAN |
Type: |
10 inch butterfly valve |
Brand: |
Top Valves |
Color: |
Bule |
General Design: |
API609 |
Mounting Pad: |
ISO 5211 |
Face to Face: |
API609,EN558 1-20 series etc |
Flange Drilling: |
DIN2501 PN10/PN16 |
Inspection and Test: |
API598 |
Body: |
Cast iron,Ductile iron |
Seat: |
EPDM. PTFE,NBR |
Packaging & Delivery
Packaging Details: | plywood boxes |
| Delivery Detail: | 30workda\ys |
Product Description
Features
1.Wide choice in Nylon 11. PTFE,CPE coated disc,Nickel coated disc,Stainless steel disc,Al-bronze disc, Aluminum alloy disc,various rubber abd PTFE of seat, Various materials of valve body, stem ans bushing,which can be suitable for different applications or meet to the specifications of customer
2.Non-pinned disc /Stem connection and automatically centered seat assure the isolation of metal fron mediun providing valve reliability,easy maintenance,the operationg torque is more lower than general butterfly valve,the life if three times of general butterfly valve.
3.Epoxy powder coated valve surface provide excellent corrosions resistance
4.Flow charateristics trend line with good throttling function
5.Bubble tighness, no leakage under the air test
6 Various operation and method of installation of installation are available according to requiremants of customers.
Meterial and Drive
cast iron , ductile iron , carbon steel . stainless steel die casting aluminum | Body |
| Ductile iron nylon coating, Polyether ch,oride coating ,PTFE coating.Plated Ductile Iron,ALuminum Bronze, Staubless Steel,Plated Carbon steel, | Disc |
| NR, NBR, CR, EPDM , Hypalon, SI , FPM,PTFE | Seat |
| Stainless steel , Plated Carbon Steel | Stem |
| Hand_lever. Gear manual Drive, Electric , Pneumatic Drive | Drive |
About-Us
Xingtai City Liqian Import & Export Co., Ltd is committed to providing high-quality industrial valves to the international customers. Our factory has a 60-year history on researching, developing, manufacturing and marketing of industrial valve products that are widely used in Oil & Gas, Water Treatment, Power Generation, Petroleum Refinery, Chemical & Petrochemical, and Paper & Pulp industries. It is located in Tianjin-Bohai Economic Center, with strong geographical advantages and development spaces, now becoming the largest valve manufacturer in China. It has passed the authentication of ISO9001:2008 quality management system, ISO 14001:2004 environmental management system, and OHSAS 18001:2007 Occupational Health & Safety System, also with CE, API, KS and Gost certification.
Our exported products include USA ANSI, API, AWWA standard valves, Germany DIN standard valves, England BS standard valves, Japan JIS standard valves, Russia GOST standard valves, France NF standard valves, etc. and the types covering gate valve, globe valve, ball valve, butterfly valve, check valve, diaphragm valve, reducing valve, plug valve, traps valve, etc. With stable quality and long using life, our valves are very popular in USA, Europe, Russia and Middle East markets.
To choose Liqian Valve means to choose safety. We would like to enjoy a win-win cooperation with the customers all over the world!
