Nickel-based alloy refers to 6.5 ~ 10 degrees Celsius higher strength and under certain oxidation corrosion ability of comprehensive performance of alloy. According to the main properties, nickel-based alloy is subdivided into heat resistance alloys, anticorrosion alloy, antifriction alloy, precision alloy and shape memory alloy etc...Also Nickel-based superalloy referred to as ni-based alloy.
Represented of Nickel-based alloy:
1. Incoloy, ( Incoloy800). Belong to heat resistance alloys.
2. Inconel, (inconel600). Belong to heat resistance alloys.
3. Hastelloy
4. Monel
According to different conditions, choose different nickel-based alloy valve material can meet various as high temperature corrosion environment.
2. Application:
As nickel-based alloy becomes higher strength and anticorrosion in oxidation at 6.5 ~ 1000 ° C temperature, Nickel-based alloy is used for aerial engines lamina, energy conversion devices etc.
Product Specifications:
1. Size: 2"~40" (DN50~DN1000).
2. Pressure: 150~600LB(PN1.0MPa~PN6.4MPa).
3. Body Materials: Incoloy800, Inconel600.
4. Operation: Lever, Gear, Electric, Pneumatic, Hydraulic
Technical Specification:
1. Design & Manufacture standard: API 600.
2. Face to face dimension standard: ASME B16.10.
3. Flange standard: ASME B16.5, ASME B16.47.
4. Test & Inspect standard: API 598.
Bason Valve Co., Ltd provides an diversity of valves' production and ODM & OEM manufacturing, these valves are widely used in Oil & Gas, Power, Chemical, Mine, Power Plants, Mining and other allied fields. All our products and quality management procedures are in accordance with ISO 9001. Our wide range of products includes:
1. Floating / Trunnion Ball valves.
2. API 600 / 602 / 603 Gate, Globe, Check valves.
3. API 594 Dual plate check valves.
4. API 609 Butterfly Valves
5. Cryogenic Valves: Used in extreme low temperature services, such as LNG & LPG, Oxygen Gas Industry.
6. Special Alloy Valves: Some of the Materials we offer are Titanium, Monel, Hastelloy, Alloy 20, Duplex/Super Duplex Steel.
7. Other valve accessories, such as pipe fittings, flanges, gaskets etc.
Size: 1/2"~48" (DN20 to 1200)
Rating: Class150 - 2500 (PN10-PN420)
Temperature: -196 to +650 degree
Connection End: Flanged, BW, SW, NPT, Wafer type etc.
Testing:
According to API598.
Non-Destructive Testing: X-ray Testing, UT Testing, Magnetic Particle testing, Dye Penetration Test
Destructive Testing: Impact Testing
Our mission is to assist our customers in obtaining the best possible solutions to their requirements and needs, at the most advantageous prices, without compromising on delivery or quality. With this in mind, we believe in developing long terms relationships based on mutual trust and honesty.
