Features
1. Electro and Mechanical Polishing
2. Sealing Material: PTFE, NBR, EPDM, FPM
3. Manufacture Standard: GB, DIN, ISO, SMS
4. Zero Leakage
5. Connection: Welding, Clamp
6. Tpye: Double-acting, Single-acting
Specifications
Inside and outside of body can be high-temperature sterilization
1). Nominal Diameter: DN15-50
2). Pressure Range: 0-16bar
3). Medium Temp: -20º C+150º C
4). Ambient Temp: -20º C+60º C
5). Diaphragm Material: EPDM, FPM, PTFE
6). Body Material: Stainless Steel
7). Body of Actuator: Aluminium Alloy
8). Connection: Tri-clamped, Welding, Flanged, Threaded
9). Driving Way: Pneumatic normally closed (1), normally open (2), double direction (3)
10). Useful: Pneumatic actuator D applied to pass body, Pneumatic actuator T applied to pass body and multiplass body
11). Max Pressure: 10 bar (diaphragm is EPDM or EPM), 6 bar (diaphragm is PTFE, one side shall be used)
12). Max Temperature: 150º C (according to the conditions of use)
13). Control Pressure: 4-6 bar (control way 1), 3-4 bar (control way 2 and 3)
We are a manufacturer specialized in producing kinds of sanitary valves and fittings. Such as butterfly valves, check valves, ball valves, diaphragam valves, sample valves, stop reversing valves, relief valves, bends, tees, reducers, unions, ferrules, etc.
Wanguo endless demands on product quality, our production line adopts the advanced"OKUMA-BYJC", CNC machining centers and CNClathes and milling centers, CNC machining centers and automated production equipment: Products in stricts accordance with DIN, SMS, 3A, IDF, ISO, RJT other domestic and international standards of design and manufacturing, quality in line with GMP Pharmacopoeia, by ISO9001, and CEcertification. Products are exported to Europe, South America, North America, SouthAsia, the Middle East and the domestic market.
Integrity, quality, development is the business philosophy of the nations. Wanguo people have been working to high quality materials, advanced equipment, stric manufacturing standards and quality assurance system combination, strive to provide the best, the best products.
Zhejiang WanGuo Fluid Equipment Technology Co., Ltd. is located in the north of Longwan District, founded in 2008. Our company is a technologically-innovative enterprise that integrates development, design, production, sale and technical services.
WanGuo specializes in designing, producing and selling high-precision sanitary pumps, butterfly valves, spherical reversing valves, safety valves, mix-proof valves, sample valves, unions, tri-clamp unions, elbows, tees and all kinds of valves and pipeline connecters. They are widely used in food, beverage, pharmaceutical, bioengineering, water treatment, chemical and other industries.
WanGuo always focuses on high quality, and we have the most advanced OKUMA-BYJC and MAZAK CNC processing equipment, machining centers, milling centers and other automatic production equipment. All of our products are strictly designed and manufactured according to international standards, such as DIN, SMS, 3A, IDF, ISO and RJT. The quality meets the full requirements of GMP, ISO9001 and CE safety standards. Our products are well recognized by clients in Europe, South America, North America, Southeast Asia, the Middle East and our country.
Honestly, quality and development are what we pursue forever. WanGuo people always perfectly combine the high-quality materials, sophisticated designs, strict manufacture process with a quality assurance system, and try our best to offer the best and high-quality products to our customers.
