1. Pressure rating: 150pls @ 73.4 º F(23º C)
2. Full port design
3. Adjustable seat tightness
4. Easy to disassemble by handle
5. Less on-line down time forreplacement/maintenance
6. Actuator could be installed with inserted nut
7. Standard product is without nut
|
Type |
Size |
Material |
Seat |
O-ring |
Standard |
End type |
|
VP-640 |
1/2"-4" |
PVC |
PTFE |
EPDM,FPM |
ANSI,JIS.DIN,BS |
Socket,Threaded,Flanged |
|
VP-641 |
1/2"-4" |
CPVC |
PTFE |
EPDM,FPM |
ANSI,JIS.DIN,BS |
Socket,Threaded,Flanged |
|
VP-643 |
1/2"-4" |
PVDF |
PTFE |
EPDM,FPM |
ANSI,JIS.DIN,BS |
Socket,Threaded,Flanged |
|
VP-644 |
1/2"-4" |
PP |
PTFE |
EPDM,FPM |
ANSI,JIS.DIN,BS |
Socket,Threaded,Flanged |
|
VP-645 |
1/2"-4" |
ABS |
PTFE |
EPDM,FPM |
ANSI,JIS.DIN,BS |
Socket,Threaded,Flanged |
|
NO |
PART |
MATERIAL |
|
1 |
BODY |
UPVC,CPVC,PP,PVDF,ABS |
|
2 |
STEM O-RING |
EPDM,FPM |
|
3 |
STEM |
UPVC,CPVC,PP,PVDF,ABS |
|
4 |
BALL |
UPVC,CPVC,PP,PVDF,ABS |
|
5 |
SEAT SEAL |
PTFE |
|
6 |
CARRIER O-RING |
EPDM,FPM |
|
7 |
SEAT CARRIER |
UPVC,CPVC,PP,PVDF,ABS |
|
8 |
UNION NUT |
EPDM,FPM |
|
9 |
SET RING |
UPVC,CPVC,PP,PVDF,ABS |
|
10 |
UNION NUT |
UPVC,CPVC,PP,PVDF,ABS |
|
11 |
HANDLE |
ABS,PP |
|
12 |
INSERTED NUT |
C3604 |
|
13 |
FLANGE |
UPVC,CPVC,PP,PVDF,ABS |
Zhejiang Theoborn Auto-Control Valves Co., Ltd. is dedicated to the manufacture of pneumatic/electric actuators and ball valves and provide good solution for automation control system.
Main Products:
1. Rack&Pinion Pneumatic actuators(Double acting/spring return type)
2. Scotch yoke pneumatic actuators(Double acting/spring return type)
3. Electric actuator (ON/OFF, modulating type)
4. Flange/thread Ball valve
5. Automation Control Accessories
Our products have passed CE certification.
