Features & Benefits
Balanced trim design reduces actuator size requirements
Large streamlined flow paths offer improved operation in dirty fluid applications
Top and bottom guiding results in smooth process control by offering stability and resulting in improved process yield
Top and bottom entry access to the valve internal components permits efficient in-line maintenance and repair
Rugged design offers durability for demanding applications and field conditions
Commonality of parts with the Masoneilan 80000 Series three-way control valve helps reduce onsite inventory requirements
Dn( mm)
|
20
|
25
|
32
|
40
|
50
|
65
|
80
|
100
|
125
|
150
|
200
|
250
|
300
|
350
|
400
|
Assento tamanho( mm)
|
20
|
25
|
32
|
40
|
50
|
65
|
80
|
100
|
125
|
150
|
200
|
250
|
300
|
350
|
400
|
avaliado kv
|
linear
|
6.9
|
11
|
17.6
|
27.5
|
44
|
69
|
110
|
176
|
275
|
440
|
630
|
1000
|
1600
|
2156
|
2816
|
igual porcentagem
|
6.3
|
10
|
16
|
25
|
40
|
63
|
100
|
160
|
250
|
400
|
690
|
900
|
1440
|
1960
|
2560
|
Pressão nominal( mpa)
|
1. 6,2. 5,4. 0,6. 4,10
|
Curso( mm)
|
16
|
25
|
40
|
60
|
100
|
130
|
Diafragma domínios eficaz( cm2)
|
280
|
350
|
560
|
900
|
1400
|
tipo pistão
|
o alcance do sinal kpa
|
20-100,40-200,80-240
|
fonte de pressão mpa
|
0.1-0.4
|
0.4-0.7
|
inerente características de fluxo
|
Linear,igualdade- percentual, rápido- aberto
|
rangeabilidadeinerente
|
50:1
|
vazamento de nível
|
Hard- sealing iv nível, soft- vi vedação
|
tamanho do flange
|
Conforme-se com jb/79.1(2)- 94, hg20592-97, gb, ansi, jis, din etc. Standard
|
material do corpo
|
Wcb, 304,316, wc 6, wc 9, ti, ni, hastelloy, monel etc.
|
flug materiais
|
304,316,420, ti, ni, hastelloy, monel etc.
|
tem de trabalho
|
- 40~+230( normal met.), +230~+45(middle met
.), +450~+560( tempe.),- 40~- 196( temperaturas baixas.)
|
tipo de série
|
Normal da temperatura, médio met, temperaturas baixas, fole de vedação tipo, jaqueta tipo deisolamento, shut- off tipo de controle
|
Shanghai ThinkTank Process Management Co., Ltd. is the sole production and R&D institute of Taiwan STONE Company in Mainland China. ThinkTank entered Chinese market in 2002 and moved from Hangzhou to Shanghai headquarter in 2012. Based on over 30 years experience in researching and manufacturing automatic instruments, brining in overseas advanced technology and combining domestic users real working situation, ThinkTank is specialized in producing new typed self-regulating valves, control valves and various kinds of automatic instruments. ThinkTank's business includes engineering projects such as electricity, metallurgy, petrochemical processing, light industry and building materials, municipal water service and natural gas.
Enterprise history
1985.08 Taiwan STONE company was established in Taipei city.
1990.02 Sales network covered Southeast Asia.
2002.06 Branch office was fund in Hangzhou, Zhejiang, handling all business in China
2012.10 Mainland head office was moved to Pudong, Shanghai
Shanghai ThinkTank Process Management Co., Ltd. Has a professional team works for control valves design and engineering application. ThinkTank develops a series of hi-tech products after absorbing overseas advanced technology and innovating.
*New self-regulating, micro pressure, differential pressure, flow, temperature control valve
*New pneumatic (electric) linear actuator (low dB, high pressure) control valve
*Pneumatic (electric) rotary actuator (O/V ball, butterfly) control valve
*Pneumatic (electric) special corrosion resisting control valve
Shanghai ThinkTank Process Management Co., Ltd sticks to the policy of "client oriented, quality comes first, and faith is root". Depending on many years experience on engineering application in various industries, ThinkTank provide clients with good, reliable full service, focusing on maximizing the rate of return on investment for clients.
