Connection dimension of flange:
PN1.0MPa, PN1.6MPa to GB4216
PN2.5MPa to GB9113
Purpose:
For the pipeline of water supply and drainage system, which need reduce the pressure.
Suitable temperature: ≤ 90º C
According to the different materials, the temperature is
Up to ≤ 250º C
Suitable medium: Water, air, noncorrosion liquid
Advantages:
Directly act on the lower part of the diaphragm (piston) by the valve-back pressure for reducing the pressure and stabilizing the pressure. It is sensitive and can be used for a long time.
Pressure rating: PN (MPa)
1.0 1.6 2.5
Tests:
Test JB/T9092, GB/T13927
Nominal pressure: PN(MPa)
Body: PN X1.5
Seal: PN X 1.1
Materials:
Body: Cast iron, carbon steel
Lower cover: Cast iron, carbon steel
Bonnet: Cast iron, carbon steel
Diaphragm: Nylon reinforcing rubber
Gasket: NBR rubber
Compression: Silicon manganese steel
Spring
Piston: Stainless steel
Cylinder: Liner Stainless steel
Stem: Stainless steel
