Pressure-seal Piston Check Valve 900Lb~2500Lb
Standard Material Specifications
NO. Part Name CS to ASTM AS to ASTM SS to ASTM
Type A105 Type F22 Type F304(L) Type F316(L)
1 Body A105 A182 F22 A182 F304(L) A182 F316(L)
2 Life Disc A276 420 A276 304 A276 304(L) A276 316(L)
3 Sealing Seat A105 F22 A182 F304(L) F316(L)
4 Pressure Ring 08F 08F A276 304L A276 316L
5 Retaining Nut A194 2H A194 4 A194 8 A194 8M
6 P. S. Lock Nut A194 2H A194 4 A194 8 A194 8M
Suitable Medium W. O. G. etc W. O. G. etc HNO3, CH3OOH etc
Suitable Temperature -29 425 -29 550 -29 180
| NPS | 1/2~ | 3/4~ | 1~ | 1-1/4~ | 1-1/2~ | 2~ |
| L | 900~1500Lb | 140 | 140 | 140 | 178 | 178 | 216 |
| 250Lb | 186 | 186 | 186 | 232 | 232 | 279 |
| H | 117 | 117 | 117 | 152 | 152 | 195 |
| Weights | 900~1500Lb | 7.5 | 7.0 | 6.8 | 18.5 | 18.1 | 20.3 |
| 2500Lb | 9.0 | 7.6 | 8.4 | 19.5 | 20.1 | 21.8 |
