Proportion Type Pressure Reducing Valve (GAYb43X)
| Price: |
US $ 1/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Paypal,Western Union |
Product: Proportion type pressure reducing valve Pressure Rating: 1.0-1.6MpaSpecification: Flanged:DN25-200, Screwed:DN15-50Material: Brass, Steel, CF8Standard flanges: DIN, ANSI, JIS; Standard screwed: NPT GAYB43X-10T/16T type copper proportional valve PN10 ~ PN16 flanged connections based on the form , piston structure, seat sealing surface material for rubber , nominal pressure PN10 ~ PN16, body material is a fixed proportion of copper reducing valve, Main structure of the body include Inlet gland , piston, Outlet gland and O-rings, gaskets and other parts. GAYB43X-10T, GAYB43X-16T -type copper proportional pressure reducing valve is to use floating piston valve cross-sectional area across different pressure differential thereby changing the inlet and outlet pressure conditions, to achieve the purpose of decompression . Structured, novel , running smooth , lightweight body for easy installation , reduced the proportion of stable , ie less " dynamic pressure " and less " static " , copper materials used for clean water and sea water, afraid of scaling and rust alone . GAY43X-10T/16T Copper Proportional Pressure Reducing Valve Specification| GAY43X-10T,GAY43X-16T Copper Proportional Pressure Reducing Valve Specification |
| Model | PN | Working Pressure/ MPa | Applicable Temperature/ ºC | Applicable Medium |
| GAY43X-10T | 10 | 1.0 | ≤90 | Water, Gas |
| GAY43X-16T | 16 | 1.6 | ≤90 | Water, Gas |
Main Parts Material | Model | Material |
| GAY43X-10T | Copper |
| GAY43X-16T | Copper |
Connecting Dimension.(mm.) | PN10. |
| Proportion | DN | D | D1 | D2 | A1 | b | z×ød | D3 | A2 |
2:1
3:1
5:2
3:2
4:3 | 25 | 115 | 85 | 65 | 115 | 16 | 4×ø14 | - | - |
| 32 | 140 | 100 | 78 | 124 | 18 | 4×ø18 | - | - |
| 40 | 150 | 110 | 85 | 132 | 18 | 4×ø18 | - | - |
| 50 | 165 | 125 | 100 | 140 | 20 | 4×ø18 | - | - |
| 65 | 185 | 145 | 120 | 155 | 20 | 4×ø18 | - | - |
| 80 | 200 | 160 | 135 | 155 | 22 | 8×ø18 | - | - |
| 100 | 220 | 180 | 155 | 200 | 24 | 8×ø18 | - | - |
| 125 | 250 | 210 | 185 | 220 | 26 | 8×ø18 | - | - |
| 150 | 285 | 240 | 210 | 230 | 28 | 8×ø22 | - | - |
| 200 | 340 | 295 | 265 | 270 | 28 | 8×ø22 | - | - |
4:1
5:1 | 25 | 115 | 85 | 65 | - | 16 | 4×ø14 | 115 | 178 |
| 32 | 140 | 100 | 78 | - | 18 | 4×ø18 | 140 | 188 |
| 40 | 150 | 110 | 85 | - | 18 | 4×ø18 | 150 | 195 |
| 50 | 165 | 125 | 100 | - | 20 | 4×ø18 | 165 | 205 |
| 65 | 185 | 145 | 120 | - | 20 | 4×ø18 | 190 | 218 |
| 80 | 200 | 160 | 135 | - | 22 | 8×ø18 | 205 | 225 |
| 100 | 220 | 180 | 155 | - | 24 | 8×ø18 | 225 | 273 |
| 125 | 250 | 210 | 185 | - | 26 | 8×ø18 | 260 | 308 |
| 150 | 285 | 240 | 210 | - | 28 | 8×ø22 | 300 | 322 |
| 200 | 340 | 295 | 265 | - | 28 | 8×ø22 | 365 | 358 |
Connecting Dimension(mm).| PN16. |
| Proportion | DN | D | D1 | D2 | A1 | b | z×ød | D3 | A2 |
2:1
3:1
5:2
3:2
4:3 | 40 | 150 | 110 | 85 | 132 | 18 | 4×ø18 | - | - |
| 50 | 165 | 125 | 100 | 140 | 20 | 4×ø18 | - | - |
| 65 | 185 | 145 | 120 | 155 | 20 | 4×ø18 | - | - |
| 80 | 200 | 160 | 135 | 155 | 22 | 8×ø18 | - | - |
| 100 | 220 | 180 | 155 | 200 | 24 | 8×ø18 | - | - |
| 125 | 250 | 210 | 185 | 220 | 26 | 8×ø18 | - | - |
| 150 | 285 | 240 | 210 | 230 | 28 | 8×ø22 | - | - |
| 200 | 340 | 295 | 265 | 270 | 30 | 12×ø22 | - | - |
4:1
5:1 | 25 | 115 | 85 | 65 | - | 16 | 4×ø14 | 115 | 178 |
| 32 | 140 | 100 | 78 | - | 18 | 4×ø18 | 140 | 188 |
| 40 | 150 | 110 | 85 | - | 18 | 4×ø18 | 150 | 195 |
| 50 | 165 | 125 | 100 | - | 20 | 4×ø18 | 165 | 205 |
| 65 | 185 | 145 | 120 | - | 20 | 4×ø18 | 190 | 218 |
| 80 | 200 | 160 | 135 | - | 22 | 8×ø18 | 205 | 225 |
| 100 | 220 | 180 | 155 | - | 24 | 8×ø18 | 225 | 273 |
| 125 | 250 | 210 | 185 | - | 26 | 8×ø18 | 260 | 308 |
| 150 | 285 | 240 | 210 | - | 28 | 8×ø22 | 300 | 322 |
| 200 | 340 | 295 | 265 | - | 30 | 12×ø22 | 365 | 358 |
| Prod Model: |
GAYB43X |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No: |
Gayb43X |
| Size: |
1/2"-8" |
| Category: |
Pressure Reducing Valve |
| Connecting Type: |
Flange or Screwed |
| Material: |
Brass,C.S or S.S |
| Medium: |
Water,Gas. |
| Working Temperature: |
Below 90 Deg C |
| Usage: |
Pressure Reducing |
| Application: |
Buildings,Pump Station,Fire Protection System.,etc |
