Specification:
1. Size: 1-1/2"-24" (DN40-DN600)
2. Design Standard: BS5163, AWWA C509/C515, DIN3202 F4/F5, MSS SP-70. Gost...
3. End Flange Connection: ANSI B 16.1, BS EN 1092(PN10, PN16), DIN 2501(PN10, PN16), BS 10 Table E
4. Disc: Grey iron, Ductile iron, with or without EPDM
5. Seat: Stainless steel, Brass/Bronze etc, Soft seat or seal: EPDM, NBR
6. Testing: API 598, ISO 5208
7. Options: Lever, Gearbox operate, Electric actuator, Pneumatic operator, Opening indicator, With limit switch, Others.
8. Type: Non rising stem, Rising stem
9. Finishing: Epoxy coating, Painting etc
10. Usage: Water supply and drainage, Electric power, Petrochemical, Metallurgical, Firefighting / Fire fighting, or other industries.
Pressure Testing & Quality Control:
Working Pressure |
10 bar / 16 bar / 125 lbs / 150 lbs etc |
Testing Pressure |
Shell: 1.5 times of wooking pressure
Seal: 1.1 times of working pressure |
Working Temperature |
-10°C to 80°C (NBR)
-10°C to 120°C (EPDM) |
Suitable Media |
Water, Oil and gas |
Parts & Materials:
Parts |
Materials |
Body |
Grey iron, Ductile iron, Carbon steel, Stainless steel |
Disc |
Grey iron, Ductile iron, Carbon steel, Stainless steel, with or without EPDM |
Seat |
EPDM / NBR / VITON / PTFE |
Stem |
Stainless steel, Brass/Bronze etc |
Bushing |
PTFE |
"O" ring |
NBR, PTFE |
Level |
Malleable iron, Carbon steel |
BIKVALVE company specializes in the production of ball valves, butterfly valves, check valves, globe valves and other valves. In the field of valves, company Poke has a rich design and production experience. All products pass through special processing equipment and meets international standards of reliability and safety. The company already has fifteen years of experience, provides customers with design solutions in various areas such as oil, chemical, gas and other fields of industry. One priority advantage of the company bikvalve is the extension of the partnership not only with China, but also with foreign countries. Our products have reasonable prices, while providing our customers with the highest quality products. The company has the possibility of fast delivery of goods.
We are able to quickly fulfill the requirements and desires of the customer! We are very glad to offer the services to meet the requirements of our clients!
