1. Low height and slim design with large merchandising area optimizes store foot ultilization;
2. Optional chiller and freezer;
3. Yhe unique anti-fog doors design is beneficial for product appearance for customers;
4. Energy saving & high efficiency options available (LED lighting, T8 lighting, ESM fan motor, Electronic expansion valve and Hot defrost);
5. Suit for city shop and hyper C-store;
6. Standard height 1.9m/2.0m;
7. Temperature range: Chiller 2C to 7C, freezer <-18C.
|
Model |
LXWXH External Dimension/mm |
Temperature Range/C |
Effective Volume/m3 |
Display Area/m3 |
Weight/kg |
|
DB-T80-1900 5DA4C |
3905*800*1900 |
2 to 7 |
1.1 |
2.20 |
715 |
|
DB-T80-1900 4DA4C |
3124*800*1900 |
2 to 7 |
1.65 |
3.30 |
600 |
|
DB-T80-1900 3DA4C |
2343*800*1900 |
2 to 7 |
2.20 |
4.40 |
445 |
|
DB-T80-1900 2DA4C |
1562*800*1900 |
2 to 7 |
2.75 |
5.50 |
330 |
|
DB-T80-2000 5DA4C |
3905*800*2000 |
2 to 7 |
1.18 |
2.4 |
765 |
|
DB-T80-2000 4DA4C |
3124*800*2000 |
2 to 7 |
1.77 |
3.60 |
640 |
|
DB-T80-2000 3DA4C |
2343*800*2000 |
2 to 7 |
2.36 |
4.80 |
475 |
|
DB-T80-2000 2DA4C |
1562*800*2000 |
2 to 7 |
2.95 |
6.00 |
350 |
|
DB-T70-1900 5DA4C |
3905*710*1900 |
2 to 7 |
0.77 |
2.20 |
740 |
|
DB-T70-1900 4DA4C |
3124*710*1900 |
2 to 7 |
1.16 |
2.30 |
620 |
|
DB-T70-1900 3DA4C |
2343*710*1900 |
2 to 7 |
1.54 |
4.40 |
460 |
|
DB-T70-1900 2DA4C |
1562*710*1900 |
2 to 7 |
1.93 |
5.50 |
340 |
