Spirax Sacro Steam Control Pilot Operated Pressure Reducing Valve (DP27)
| Price: |
US $ 1/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Paypal,Western Union |
DP27 pilot operated pressure reducing valvePressure Rating:1.6~2.5Mpa.Specification:DN15~50mmMaterial:Steel WCB.Standard flange:DIN,ANSI,JIS.DP27 pilot operated pressure reducing valve is the new type pilot extrahuge membrane pressure reducing valve developed by our company.It is greatly improved on basis of normal pressure reducing valve.The membrane use new material ,enlarging the working area,so the slight change of upper pressure or lower pressure can be fed back to the membrane of main valve,and adjust the opening of main valve to ensure the constant pressure of lower steam pressure.Note:A variable rate conical pressure adjustment spring is fitted providing a down stream range of 0.2-17bar g.| DP27 Pilot Operated Pressure Reducing Valve's main technical parameters and indexes of performance. |
| Nominal pressure | PN25 |
| Maximum design pressure(PMA) | 25bar g@ 120 |
| Maximum design temperature(TMA) | 232@21 bar g |
| Minimum design temperature(TMI) | -10 |
| Maximum upstream pressure for saturated steam service(PMO) | 17barg |
| Maximum operating temperature(TMO) | 232@21barg |
| Minimum operating temperature(TMIO) | 0 |
| Maximum differential pressure | 17bar |
| Down stream pressure range | 0.2-1.7barg |
| Maximum cold hydraulic test pressure | 38bar g |
DP27 pressure reducing valve ' material of main component.| Name of component | Material of component |
| Valve body,valve cover | WCB |
| Valve seat | 2Cr13 |
| Valve flap | 2Cr13 |
| Valve rod | 2Cr13 |
| Membrane | brass |
| Adjusting spring | 60Si2Mn |
DP27 pressure reducing valve' connection (mm).| DN | L | H1 | H | D |
| 15 | 147 | 221 | 133 | 185 |
| 20 | 154 | 224 | 136 | 185 |
| 25 | 160 | 235 | 145 | 207 |
| 32 | 180 | 236 | 156 | 207 |
| 40 | 200 | 238 | 176 | 255 |
| 50 | 230 | 246 | 183 | 255 |
| 65 | 250 | 295 | 200 | 320 |
| 80 | 310 | 323 | 230 | 350 |
| 100 | 350 | 340 | 263 | 380 |
| 125 | 400 | 359 | 306 | 455 |
| 150 | 450 | 375 | 330 | 500 |
| Prod Model: |
GADP27 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No: |
Gadp27 |
| Size: |
1/2"-6" |
| Category: |
Pressure Reducing Valve |
| Connecting Type: |
Flange |
| Material: |
C.S |
| Medium: |
Steam., etc |
| Working Temperature: |
Bellow 285 Deg C |
| Usage: |
Pressure Reducing |
| Application: |
Steam System, Air Compressor System., etc |
