1.Product features:
1. The ultra structure of short length, save material, can make the pipeline system greatly reduce the overall weight.
2. Taking up the effective space is little, can effectively support the pipeline strength, can reduce the possibility of pipeline vibration.
3. On PTFE packing using the flexible, reliable seal, flexible operation of the light.
4. The damper has the function of knife can effective brake circuit medium of various kinds of sundry.
2.Materials of Main Parts:
Body and cover |
gate valve |
stem |
sealing face |
Stainless steel, carbon steel,
gray cast iron |
Carbon steel, stainless steel |
SS |
Rubber, ptfe, stainless steel,
cemented carbide |
3.Main Performance Specification:
Nominal pressure (MPa) |
Shell Test (MPa) |
Seal test
(MPa) |
Working
temperature |
Applicable medium |
1.0 |
1.5 |
1.1 |
≤100°C |
Pulp, waste water,
coal slurry, slag, ash
and water mixture |
1.6 |
2.4 |
1.8 |
≤100°C |
