Stainless Steel Resilient Seated Gate Valve

Stainless Steel Resilient Seated Gate Valve
Price: US $ 29-49/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Paypal
Resilient seated gate valve face to face dimension according to EN 558, Series 14 and Series 15 with electric actuator.
Available with AUMA NORM or AUMA MATIC actuator
Reduced operating torque
Easily replaceable component parts
Waterthightness through the spindle is optained with four dynamic o-rings and a spindle dustguard in order to avoid impurities
Seals are cabable of being replaced with the valve under pressure and in the fully opened position
Stem is made to be able to withstand without permanent distortion all stresses, compressive, tensile and torsional, to which it could be subjected in normal service
Wedge nut is a fully replaceable part, with a screw thread to match the screw thread on the stem
All pressure-contained cast iron components are coated to provide protection against corrosion
Bolting according to DIN 912 in 8.8 steel with organic coating countersunk, and with seal protection. Stainless steel AISI 302 is available as an option
Full and straight bore in order to avoid turbulence, loss of head and effect
All valves have foot support
The valves are delivered with square cap or handwheel

DNISO 2531 PN 10ABD1EN 558 (DIN 3202)Weight, kgNo. of turns for closing
DKGbNo. x dF14 (F4)F15 (F5)F14 (F4)F15 (F5)

1Body1GGG-50DIN EN 1563
2Bonnet1GGG-50DIN EN 1563
3Wedge1GGG-50DIN EN 1563
4Wedge coating1NBR / EPDMUNE-EN 681-1
5Stem1X20 Cr13BS 970
6Wedge lock nut1Copper alloyUNE-EN 12165
7Body bonnet gasket1EPDM / NBRUNE-EN 681-1
8Packing2NBR / EPDMUNE-EN 681-1
9Body bonnet boltacc./DNSteel 8.8 Js-500
10Packing gland1Bronze Rq.5DIN 1705
11Stuffing gland1Bronze Rq.5DIN 1705
12O-Ring1NBRASTM D2000
13Packing string2PTFE-Graphite
14Stuffing bonnet1GGG-50DIN EN 1563
15Threaded stickacc./DNX5 CrNi 18 10DIN 17440
16Washeracc./DNX5 CrNi 18 10DIN 17440
17Nutacc./DNX5 CrNi 18 10DIN 17440
18Top bonnet1GGG-50DIN EN 1563
19Stem nut1Bronze Rq.5DIN 1705
Prod Model: FYV
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dn40-600: Pn10-16
Size: 2''-48''
Ends Con.: Bw,Sw,Rtj,RF
O-Ring Sealing: PTFE,NBR,Rptfe
Connection Form: Flange
Material: Stainless Steel
Seal Surface: Wedge Gate Valve
Thread Position Of Valve Rod: Inside Gate Valve
Application: Industrial Usage
Fangyuan Valve Group Co. Ltd, seated at Wuxing Industrial Zone, Oubei, Yongjia County, so called as "Pump & Valve Village of China", close to the national scenic spot Nanxijiang River to the east and facing the downtown of Wenzhou City to the south, and established in 1998 with the former as Zhejiang Fangyuan Valve Manufacturing Co. Ltd, has got a great achievement via hard work and continual going forth ahead and become a magnate of plate gate valve from an unknown small enterprise and leads the future of this industry. Fangyuan Valve Group Co. Ltd was derived from Zhejiang Fangyuan Valve Manufacturing Co. Ltd in 2005 and holds 5 stock subsidiaries, three production bases in Wenzhou, Shanghai and Lishui and a cast base in Lishui, a total registered capital up to 4, 000, 000 USD, a total land area 110000m2, over 600 staff members, 60 of which are technicians, a digital process center and more than 350 sets of various middle and large equipments and an annual output up to 12000 tons.

This Group comes as a key enterprise among the said"Pump & Valve Village of China"and a well known enterprise in the national valve industry and specializes in the production of plate gate valve, gas valve, electric station valve etc., with the development, design and invention patent know-how up to the advanced technical level of the world and the leading level of the nation and some of the products used to replace the imported ones. This Group has been accredited to ISO9001, API6A/6D, CE, AZ etc., won the first prize of scientific advance of Zhejiang Province and elected as a member of the first-grade supply network of China Petroleum, a member of China Petrochemical Resource Market, a member of No. 1 Energy Network, a member for supply of the national electric power system, an appointed production enterprise by Chemical Equipment General Corp., a Wenzhou high-tech enterprise, a start enterprise of Yongjia County, one of the 30 powerful enterprises among the said village and a banking credit AAA grade enterprise in the successive recent years. It holds a powerful strength in the technical, management and market etc. Respects and a notable superiority in the severe market competition.

The products, approved by the nation and province early or late, have been elected as quality products of Zhejiang Province and well-known ones of Wenzhou. This Group follows the guide policy of"takeing people as the base, managing the company with laws, prospecting the enterprise with quality, continuing innovations"and makes the products well sold to all over the country and USA, Canada, the Middle East, Europe etc. World markets, greatly favored by the users therein. Therefore a solid basis has been made for the further open-up of the world market, for the making of Fangyuan brand, for the national industrial progression and for the great target to create a valve magnate of China and step forward to the 50 powerful valve companies of the world.

Slab gate valve: Slab gate and expanding gate, double sealed upstream and downstream design, double block and bleed open and closed design. Size: DN50~DN1400, pressure: PN16~PN420, handwheel, gear, electric, pneumatic.

Fully welded ball valve.

Forged steel valve. Material: A105, LF2, F11, F22, F5, F304, F316, F321 etc.
